Wichita Clutch AquaMaKKs Water Cooled Clutches and Brakes
Wichita Clutch AquaMaKKs Water Cooled Clutches and Brakes
SKU:CLU-fc9735
High-performance Wichita Clutch AquaMaKKs Water Cooled Clutches and Brakes for industrial applications.
Regular price
$2,150.00
Regular price
Sale price
$2,150.00
Unit price
per
Initiate Order
Wichita Clutch AquaMaKKs Water Cooled Clutches and Brakes
$2,150.00
Quantity: 1
Claim Your Seller Account
Wichita Clutch AquaMaKKs Water Cooled Clutches and Brakes
$2,150.00
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wichita Clutch AquaMaKKs Water Cooled Clutches and Brakes with Composite Water Jacket offer exceptional performance for industrial applications. Pneumatically or hydraulically controlled, these clutches and brakes feature copper wear plates for superior heat dissipation. Available in 19", 25", and 36" diameters, with torque ranges from 66,500 in.lb. to 1,611,000 in.lbs., these units ensure reliable operation under varying loads. Designed with a dynamic torque rating, heat capacity options, and precision construction, they meet the rigorous demands of industrial settings.
Product Specifications
Specifications Actuation
Air Applied
Specifications Assembly Number
7-219AM-W-1300
Specifications Bolt Circle Diameter C
0.656 in | 17 mm
Specifications Diameter A
28.30 in | 719 mm
Specifications Diameter B
28.3 in | 719 mm
Specifications Dynamic Torque Rating 100 Psi7 Bar
181400 lb·in | 20480 Nm
Specifications Dynamic Torque Rating 80 Psi55 Bar
133000 lb·in | 15016 Nm
Specifications Heat Capacity For Parallel Water Hosing
370 hp | 276 kW
Specifications Heat Capacity For Series Water Hosing
185 hp | 138 kW
Specifications Holes Quantity
10
Specifications Hole Circle
22 in | 559 mm
Specifications Inner Diameter Length F
18.25 in | 464 mm
Specifications Length A
16.84 in | 428 mm
Specifications Length C
6.84 in | 174 mm
Specifications Length D
1.25 in | 32 mm
Specifications Length E
6.88 in | 175 mm
Specifications Manufacturer
Wichita Clutch
Specifications Maximum Bore Size
5.63 in | 143 mm
Specifications Outer Diameter Length F
23.25 in | 591 mm
Specifications Pilot Diameter B
11 in | 279 mm
Specifications Plt Thickness
1.38 in | 35 mm
