The Wichita Low Inertia Air Tube Disc Brakes merge the superior features of disc clutch technology with the efficiency of direct air engagement. Engineered by Wichita Clutch, these brakes offer exceptional dynamic torque ratings, reaching up to 2375 Nm at 100 psi, making them ideal for applications requiring precise and reliable braking performance. With a maximum bore size of 2.25 inches, these brakes can handle air pressure up to 130 psi. The lightweight design, weighing only 87 lbs, houses a robust hub and center plate for enhanced durability and performance.
Product Specifications
Note 0
Consult Factory for Special Assembly Number.For mounting, use socket head capscrews conforming to the ASTM-574-97a.(Consult factory for drawing before final layout.)
Specifications Actuation
Air Applied
Specifications Assembly Number
7-008-300-100-0
Specifications Dynamic Torque Rating 100 Psi7 Bar
21000 lb·in | 2375 Nm
Specifications Dynamic Torque Rating 80 Psi55 Bar
16800 lb·in | 1865 Nm
Specifications Manufacturer
Wichita Clutch
Specifications Maximum Air Pressure
130 psi | 9 bar
Specifications Maximum Bore Size
2.25 in | 57 mm
Specifications Maximum Rpm High Speed Airtube
4300 rpm
Specifications Maximum Rpm Standard Airtube
2870 rpm
Specifications Total Brake Weight
87 lb | 39 kg
Specifications Weight Hub Center Plate
28 lb | 12.7 kg
Specifications Wr2jmr2 Hub Center Plate
2.00 lb·ft² | 0.084 kg·m²
