Wichita Low Inertia Air Tube Disc Clutches
Wichita Low Inertia Air Tube Disc Clutches
SKU:CLU-c94663
Optimal performance with Wichita's Low Inertia Air Tube Disc Clutches. Direct air engagement for trouble-free operation. Dynamic torque up to 4207500 lb·in.
Regular price
$4,850.00
Regular price
Sale price
$4,850.00
Unit price
per
Initiate Order
Wichita Low Inertia Air Tube Disc Clutches
$4,850.00
Quantity: 1
Claim Your Seller Account
Wichita Low Inertia Air Tube Disc Clutches
$4,850.00
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Experience optimal performance with the Wichita Low Inertia Air Tube Disc Clutches. Combining the best features of disc clutches with direct air engagement, these clutches offer a trouble-free method of applying axial pressure. With dynamic torque ratings up to 4207500 lb·in, a maximum bore size of 18.00 in, and a maximum air pressure of 130 psi, these clutches are designed for high-demand applications. Manufactured by Wichita Clutch, these clutches ensure reliable operation and precision.
Product Specifications
Note 0
Consult Factory for Special Assembly Number.For mounting, use socket head capscrews conforming to the ASTM-574-97a.(Consult factory for drawing before final layout.)
Specifications Actuation
Air Applied
Specifications Assembly Number
6-048-300-110-0
Specifications Balance Speed
275 rpm
Specifications Dynamic Torque Rating 100 Psi7 Bar
4207500 lb·in | 453600 Nm
Specifications Dynamic Torque Rating 80 Psi55 Bar
3366000 lb·in | 356400 Nm
Specifications Exhaust Coefficients Operating Air Pressure At 75
2.4
Specifications Manufacturer
Wichita Clutch
Specifications Maximum Air Pressure
130 psi | 9 bar
Specifications Maximum Bore Size
18.00 in | 455 mm
Specifications Maximum Rpm High Speed Airtube
700 rpm
Specifications Maximum Rpm Standard Airtube
400 rpm
Specifications Total Clutch Inertia
18000 lb·ft² | 759 kg·m²
Specifications Total Clutch Weight
6540 lb | 2966 kg
Specifications Weight Hub Center Plate
2950 lb | 1338 kg
Specifications Wr2jmr2 Hub Center Plate
4925 lb·ft² | 208 kg·m²
