Wichita Standard Vent Clutch
Wichita Standard Vent Clutch
SKU:CLU-ddd3ca
Experience reliable power transmission with the Wichita Standard Vent Clutch, designed for smooth starts and precise control in demanding applications.
Regular price
$5,699.99
Regular price
Sale price
$5,699.99
Unit price
per
Initiate Order
Wichita Standard Vent Clutch
$5,699.99
Quantity: 1
Claim Your Seller Account
Wichita Standard Vent Clutch
$5,699.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wichita Standard Vent Clutch offers reliable power transmission with a sophisticated air-tube design, ensuring swift engagement and disengagement. Designed to handle large inertia loads, this clutch provides smooth and controlled starts, ideal for demanding applications. With a slip torque capacity of 654,000 lb·in at 100 psi, it delivers exceptional performance. Wichita Clutch's expertise guarantees quality and durability, meeting the highest industry standards for institutional and government procurement requirements.
Product Specifications
Note 0
Maximum air pressure - 100 PSI
Specifications Actuation
Air Applied
Specifications Driving Ring Friction Disc Weight
265
Specifications Driving Ring Friction Disc Wr2
460
Specifications Hi Speed Airtube Maximum Speed
1100 rpm
Specifications Lining Area
1664 in²
Specifications Manufacturer
Wichita Clutch
Specifications Maximum Horsepower Per 100 Rpm Duty A
1038 hp
Specifications Maximum Horsepower Per 100 Rpm Duty B
760 hp
Specifications Maximum Horsepower Per 100 Rpm Duty C
380 hp
Specifications Maximum Horsepower Per 100 Rpm Duty D
200 hp
Specifications Recommended Clearance
1/8 to 3/16 in
Specifications Slip Torque Capacity At 100 Psi 3 Cf
654000 lb·in
Specifications Total Weight
1375 lb
Specifications Total Wr2
1350 lb/ft²
