High-quality Wieland 1.5 kV Impulse Voltage Female Insert for industrial multipole connectors, featuring 20-pole female contact, crimp connection, and V0 inflammability class. Compliant with RoHS and REACH-SVHC standards.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
Wieland 1.5 kV Impulse Voltage Female Insert - Modular Connectors
$29.99
Quantity: 1
Claim Your Seller Account
Wieland 1.5 kV Impulse Voltage Female Insert - Modular Connectors
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland 1.5 kV Impulse Voltage Female Insert is a high-quality industrial multipole connector component featuring a 20-pole female contact design with a 250V/10A rating. It offers crimp connections with stamped contacts for reliable performance. With V0 inflammability class, gray color, and 500 mating cycles, this modular insert ensures durability and safety. Operating within a temperature range of -40°C to 120°C, this Wieland female insert is compliant with RoHS and REACH-SVHC standards, ideal for various applications requiring robust connectivity solutions.
Product Specifications
Classification Eclass 81 Classification
27440205
Classification Etim 30 Classification
EC000438
Classification Etim 40 Classification
EC000438
Classification Etim 50 Classification
EC000438
Classification Etim 60 Classification
EC000438
Classification Etim 70 Classification
EC000438
Connection Data Connection Type
Crimp
Connection Data Number Of Poles
20
Connection Data Protective Contact
No
Connection Data Total Number Of Poles Without Ground Contact
20
Connection Data With Wire Protection
No
Contacts Contact Resistance
⤠5 mΩ
Contacts Surface
Gilt
Contacts Wire Strip Length
3 mm
General Brands
Wieland
General Color
Gray
General Inflammability Class Of Insulation Material According Wi
V0
General Mating Cycles
500
General Maximum Operating Temperature Range
120 ºC
General Minimum Operating Temperature Range
-40 ºC
General Model
Female Insert
General Modular Version
Yes
General Pollution Degree
3
Model With Housing
No
Product Compliance Reach Svhc Conformity Status
Compliant
Product Compliance Rohs Conformity Status
Compliant
Technical Data Din En 61984 Maximum Rated Voltage Faceground
100 V
Technical Data Din En 61984 Nominal Current
4 A
Technical Data Din En 61984 Nominal Voltage
100 V
Technical Data Din En 61984 Rated Impulse Voltage
1.5 kV
Technical Data Ulcsa Flexible Wire Conductor Cross Section
28-20 AWG
Technical Data Ulcsa Maximum Flexible Wire Conductor Cross Secti
0.5 mm²
Technical Data Ulcsa Maximum Rated Voltage According To Underwri
60 V
Technical Data Ulcsa Minimum Flexible Wire Conductor Cross Secti
0.09 mm²
Technical Data Ulcsa Rated Current According Canadian Standards
5 A
Technical Data Ulcsa Rated Current According Underwriters Labora
5 A
