The Wieland 1.5 kV Impulse Voltage Pin Insert is a high-quality modular connector designed for industrial multipole connectors. With a V0 inflammability class, gilt surface contacts, and a rated impulse voltage of 1.5 kV, this pin insert ensures reliable and safe connections. It features 20 poles, crimp connections, and stamped contacts for durability. Operating within a temperature range of -40°C to 120°C, this gray pin insert is RoHS and REACH-SVHC compliant, making it ideal for both consumer and institutional buyers.
Product Specifications
Classification Eclass 81 Classification
27440205
Classification Etim 30 Classification
EC000438
Classification Etim 40 Classification
EC000438
Classification Etim 50 Classification
EC000438
Classification Etim 60 Classification
EC000438
Classification Etim 70 Classification
EC000438
Connection Data Connection Type
Crimp
Connection Data Number Of Poles
20
Connection Data Protective Contact
No
Connection Data Total Number Of Poles Without Ground Contact
20
Connection Data With Wire Protection
No
Contacts Contact Resistance
⤠5 mΩ
Contacts Surface
Gilt
Contacts Wire Strip Length
3 mm
General Brands
Wieland
General Color
Gray
General Inflammability Class Of Insulation Material According Wi
V0
General Mating Cycles
500
General Maximum Operating Temperature Range
120 ºC
General Minimum Operating Temperature Range
-40 ºC
General Model
Pin Insert
General Modular Version
Yes
General Pollution Degree
3
Model With Housing
No
Product Compliance Reach Svhc Conformity Status
Compliant
Product Compliance Rohs Conformity Status
Compliant
Technical Data Din En 61984 Maximum Rated Voltage Faceground
100 V
Technical Data Din En 61984 Nominal Current
4 A
Technical Data Din En 61984 Nominal Voltage
100 V
Technical Data Din En 61984 Rated Impulse Voltage
1.5 kV
Technical Data Ulcsa Flexible Wire Conductor Cross Section
28-20 AWG
Technical Data Ulcsa Maximum Flexible Wire Conductor Cross Secti
0.5 mm²
Technical Data Ulcsa Maximum Rated Voltage According To Underwri
60 V
Technical Data Ulcsa Minimum Flexible Wire Conductor Cross Secti
0.09 mm²
Technical Data Ulcsa Rated Current According Canadian Standards
5 A
Technical Data Ulcsa Rated Current According Underwriters Labora
5 A
