Wieland 110V 1W 250V6A-F Relay Module
Wieland 110V 1W 250V6A-F Relay Module
SKU:COU-bdadf2
Reliable Wieland 110V 1W 250V6A-F Relay Module with 6.2mm width, 1 change-over contact, and spring clamp terminal. IP20 protection, polarity-free drive, RoHS compliant.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
Wieland 110V 1W 250V6A-F Relay Module
$29.99
Quantity: 1
Claim Your Seller Account
Wieland 110V 1W 250V6A-F Relay Module
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland 110V 1W 250V6A-F Relay Module is a reliable coupling relay with a solid-state design, featuring 6.2mm width, 1 change-over contact, and spring clamp terminal for secure connections. It operates on 110V AC/DC input with 250V AC/6A output capacity, ensuring efficient voltage and current control. With a compact design and compliance with IP20 protection standards, this relay module offers polarity-free drive and mono-stable function, complete with socket for easy installation. RoHS and REACH-SVHC compliant.
Product Specifications
Classification Eclass 81 Classification
27371601
Classification Etim 30 Classification
EC001437
Classification Etim 40 Classification
EC001437
Classification Etim 50 Classification
EC001437
Classification Etim 60 Classification
EC001437
Classification Etim 70 Classification
EC001437
Dimensions Depth
70 mm
Dimensions Height
98 mm
Dimensions Width
6.2 mm
General Brands
Wieland
General Complete With Socket
Yes
General Connection Type
Spring Clamp Connection
General Degree Of Protection Ip
IP20
General Detachable Clamps
No
General Forced Guided Contacts
No
General Function Drive
Mono Stable
General Model
RELAY MODULE FLARE-110V-1W-250V6A-F
General Number Of Change Over Contacts
1
General Polarization Drive
Polarity Free
Product Compliance Reach Svhc Conformity Status
Compliant
Product Compliance Rohs Conformity Status
Compliant
Technical Data Direct Current Dc Lower Nominal Voltage
97.75 V
Technical Data Direct Current Dc Upper Nominal Voltage
126.5 V
Technical Data Maximum Rated Frequency Auxiliarycontrol Current
50 Hz
Technical Data Minimum Direct Current Dc Nominal Voltage
115 V
Technical Data Minimum Rated Frequency Auxiliarycontrol Current
50 Hz
Technical Data Type Of Excitation
Alternating Current (AC)
