The Wieland 15 Inch Diagonal Screen HMI Panel is a high-quality human-machine interface designed for industrial applications. Featuring a TFT display with a resolution of 1024x768 pixels and IP66 protection on the front side, this panel offers exceptional durability and clarity. Equipped with 64 MB RAM, USB Host/Client, Ethernet connectivity, and Modbus TCP support, it ensures seamless integration and communication within your system. The panel is programmable using the hmiPLAN software, allowing for customization to suit specific operational needs.
Product Specifications
Accessories Accessories
Part NumberHMI-Plan License (ZW.000.0170.0)DescriptionSingle-user license for hmiPLAN, configuration software for HMI applications and visualizationClassificationECLASS 11 - 27242592ECLASS 8.1 - 27249209ETIM 9.0 - EC002584ETIM 8.0 - EC002584ETIM 7.0 - EC002584ETIM 6.0 - EC002584ETIM 5.0 - EC002584ETIM 4.0 - EC002584
Classification Eclass 11 Classification
27242301
Classification Eclass 81 Classification
27242301
Classification Etim 40 Classification
EC001414
Classification Etim 50 Classification
EC001414
Classification Etim 60 Classification
EC001414
Classification Etim 70 Classification
EC001414
Classification Etim 80 Classification
EC001414
Classification Etim 90 Classification
EC001414
Dimensions Build In Depth
57.5 mm
Dimensions Cutout Height
283 mm
Dimensions Cutout Width
384.5 mm
Dimensions Height Of The Front
297.6 mm
Dimensions Weight
3 g
Dimensions Width Of The Front
399.1 mm
Display Backlight Life
20000 h
Display Central Processing Unit Cpu Type
RISC ARM9 32 Bit
Display Maximum Colors
16 bits
Display Number Of Horizontal Pixels
1024
Display Number Of Vertical Pixels
768
Display Screen Diagonal
15 in
Display Touch Technology
Resistive Touch
Display Type Of Display
Thin Film Transistor (TFT) Colour Liquid Crystal Display (LCD) with Light Emitting Diode (LED) Backlight
Product Compliance Reach Svhc Cas Numbers
7439-92-1
Product Compliance Reach Svhc Conformity Status
Duty-To-Declare
Product Compliance Reach Svhc Substances
Lead
Product Compliance Rohs Conformity Status
Compliant/Exempted
Product Compliance Rohs Exceptions
III-6(a) | III-6(c) | III-7(a) | III-7(c)I
Specifications Model
HMI-ECO-150
Supply Circuit Direct Current Dc Rated Consumption
20 W
Supply Circuit Maximum Rated Supply Voltage At Direct Current Dc
26.4 V
Supply Circuit Minimum Rated Supply Voltage At Direct Current Dc
21.6 V
Supply Circuit Voltage Type
DC
Technical Data Approvals
Yes
Technical Data Battery Backed Ram
Yes
Technical Data Compatible Plc Families
Allen Bradley | Beckhoff | Schneider | Siemens | u.v.a. | Wago
Technical Data Cooling
Natural Cooling with Minimum 50 mm Distance to Environment
Technical Data Degree Of Protection Ip
IP66
Technical Data Power Supply Type
SELV (UL 508, UL 248)
