Wieland 16-Pole Aluminum Industrial Connector Housing
Wieland 16-Pole Aluminum Industrial Connector Housing
SKU:IND-20d01a
Wieland 16-Pole Aluminum Industrial Connector Housing, Low Profile Design, Double Locking Levers, Threaded M40 Top Hole, UV Resistant, -40°C to 120°C
Regular price
$69.99
Regular price
Sale price
$69.99
Unit price
per
Initiate Order
Wieland 16-Pole Aluminum Industrial Connector Housing
$69.99
Quantity: 1
Claim Your Seller Account
Wieland 16-Pole Aluminum Industrial Connector Housing
$69.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland HOOD BAS GOT GC 16HM40 50 A1 Multi-Pole Heavy-Duty Industrial Connector Housing is a top-quality solution for industrial multipole connectivity. Constructed from durable aluminum with a gray powder coating, it ensures longevity and reliability in various environments. Featuring a low profile design, double locking levers, and a threaded M40 top hole, this housing offers secure cable connections. With a temperature range from -40°C to 120°C, UV resistance, and compliance with REACH-SVHC standards, this housing guarantees safety and performance.
Product Specifications
Classification Eclass 81 Classification
27440202
Classification Etim 30 Classification
EC000437
Classification Etim 40 Classification
EC000437
Classification Etim 50 Classification
EC000437
Classification Etim 60 Classification
EC000437
Classification Etim 70 Classification
EC000437
General Brands
Wieland
General Color
Gray
General Degree Of Protection Ip
Other
General Housing Material
Aluminum
General Inflammability Class Of Insulation Material According Wi
Other
General Maximum Operating Temperature Range
120 ºC
General Minimum Operating Temperature Range
-40 ºC
General Model
HOOD BAS GOT GC 16HM40 50 A1
General Surface
With Powder Coating
General Ultraviolet Uv Resistant
Yes
Model Cable Entry
Above
Model Construction
16H
Model Emc Version
No
Model Height
76 mm
Model Hinged Lid
No
Model Length
94 mm
Model Locking Mechanism
Double Locking Levers
Model Thread Size M
40
Model Type
Male
Model Type Of Cable
Thread
Model Width
56 mm
Model With Cable Screw Gland
No
Product Compliance Reach Svhc Conformity Status
Compliant
Specifications Number Of Poles
16
Specifications Profile
Low
