Wieland 16-Pole Heavy-Duty Industrial Connector Housing
Wieland 16-Pole Heavy-Duty Industrial Connector Housing
SKU:IND-b55aed
Durable Wieland 16-Pole Industrial Connector Housing for secure and reliable connections in challenging industrial environments. IP54 rated with aluminum construction.
Regular price
$79.99
Regular price
Sale price
$79.99
Unit price
per
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.

The Wieland 16-Pole Heavy-Duty Industrial Connector Housing is a robust solution designed for industrial applications, featuring a single locking lever with a trumpet gland M25 for secure connections. Constructed from durable aluminum with a gray powder coating, this IP54 rated housing ensures protection against dust and water ingress. With a low profile design and UV resistance, it offers reliable performance in a wide temperature range from -40°C to 120°C. Ideal for institutional and government procurement needs, this Wieland connector housing meets RoHS compliance with exceptions, making it a reliable choice for demanding industrial settings.
Product Specifications
Classification Eclass 81 Classification
27440202
Classification Etim 30 Classification
EC000437
Classification Etim 40 Classification
EC000437
Classification Etim 50 Classification
EC000437
Classification Etim 60 Classification
EC000437
Classification Etim 70 Classification
EC000437
General Brands
Wieland
General Color
Gray
General Degree Of Protection Ip
IP54
General Housing Material
Aluminum
General Inflammability Class Of Insulation Material According Wi
Other
General Maximum Operating Temperature Range
120 ºC
General Minimum Operating Temperature Range
-40 ºC
General Model
HOOD BAS GOT GG 16 M25 A3
General Surface
With Powder Coating
General Ultraviolet Uv Resistant
Yes
Model Cable Entry
Sideways
Model Construction
16
Model Emc Version
No
Model Height
60 mm
Model Hinged Lid
No
Model Length
94 mm
Model Locking Mechanism
Single Locking Lever
Model Thread Size M
25
Model Type
Male
Model Type Of Cable
Gland nut
Model Width
43 mm
Model With Cable Screw Gland
Yes
Product Compliance Reach Svhc Cas Numbers
7439-92-1
Product Compliance Reach Svhc Conformity Status
Duty-To-Declare
Product Compliance Reach Svhc Substances
Lead
Product Compliance Rohs Conformity Status
Compliant with Exceptions
Product Compliance Rohs Exceptions
III-6(a); III-6(c)
Specifications Number Of Poles
16
Specifications Profile
Low
