Wieland 16-Pole Industrial Connector Housing with Double Locking Levers and Cable Gland M25
Wieland 16-Pole Industrial Connector Housing with Double Locking Levers and Cable Gland M25
SKU:IND-da374a
Enhance connectivity with Wieland 16-Pole Industrial Connector Housing, featuring double locking levers, IP54 protection, and RoHS compliance.
Regular price
$74.99
Regular price
Sale price
$74.99
Unit price
per
Initiate Order
Wieland 16-Pole Industrial Connector Housing with Double Locking Levers and Cable Gland M25
$74.99
Quantity: 1
Claim Your Seller Account
Wieland 16-Pole Industrial Connector Housing with Double Locking Levers and Cable Gland M25
$74.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Upgrade your industrial connectivity with the Wieland BOTTOM BAS GUT GB 16 M25 A0 Multi-Pole Heavy-Duty Industrial Connector Housing. Crafted from durable aluminum with a powder coating, this 16-pole housing ensures reliable performance in diverse environments. Featuring double locking levers, it provides secure cable connections with IP54 protection. With a temperature range from -40°C to 120°C, UV resistance, and RoHS compliance, this housing guarantees safety and durability for your applications.
Product Specifications
Classification Eclass 81 Classification
27440202
Classification Etim 30 Classification
EC000437
Classification Etim 40 Classification
EC000437
Classification Etim 50 Classification
EC000437
Classification Etim 60 Classification
EC000437
Classification Etim 70 Classification
EC000437
General Brands
Wieland
General Color
Gray
General Degree Of Protection Ip
IP54
General Housing Material
Aluminum
General Inflammability Class Of Insulation Material According Wi
Other
General Maximum Operating Temperature Range
120 ºC
General Minimum Operating Temperature Range
-40 ºC
General Model
BOTTOM BAS GUT GB 16 M25 A0
General Surface
With Powder Coating
General Ultraviolet Uv Resistant
Yes
Model Cable Entry
Two-sided
Model Construction
16
Model Emc Version
No
Model Height
57 mm
Model Hinged Lid
No
Model Length
117 mm
Model Locking Mechanism
Double Locking Levers
Model Thread Size M
25
Model Type
Surface Mounting (Base)
Model Type Of Cable
Gland nut
Model Width
57 mm
Model With Cable Screw Gland
Yes
Product Compliance Reach Svhc Cas Numbers
7439-92-1
Product Compliance Reach Svhc Conformity Status
Duty-To-Declare
Product Compliance Reach Svhc Substances
Lead
Product Compliance Rohs Conformity Status
Compliant with Exceptions
Product Compliance Rohs Exceptions
III-6(c)
Specifications Number Of Poles
16
Specifications Profile
Low
