Wieland 2-Pole Female Connector, Pebble Gray - 20A, Outdoor Rated
Wieland 2-Pole Female Connector, Pebble Gray - 20A, Outdoor Rated
SKU:CIR-199f11
High-quality Wieland 2-Pole Female Connector in Pebble Gray for outdoor use. Screw connection, 20A, IP69, Type 4X/6P rated.
Regular price
$24.99
Regular price
Sale price
$24.99
Unit price
per
Initiate Order
Wieland 2-Pole Female Connector, Pebble Gray - 20A, Outdoor Rated
$24.99
Quantity: 1
Claim Your Seller Account
Wieland 2-Pole Female Connector, Pebble Gray - 20A, Outdoor Rated
$24.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland 2-Pole Female Connector in Pebble Gray is a high-quality pluggable electrical connector designed for outdoor use. With a screw connection and a rated current of 20A, this connector is suitable for cables with diameters ranging from 6mm to 10mm. It meets IP69 and Type 4X / 6P protection standards, making it robust and reliable for various applications. Compliant with international standards and suitable for both consumer and institutional buyers.
Product Specifications
Note Note
Technical details are subject to change
Specifications Angle Of Plug
Straight
Specifications Color Of Codingcontact Carrier
Pebble Gray
Specifications Connection Type
Screw Connection
Specifications Number Of Poles
2
Specifications Type
Female
Technical Data Alternating Current Ac Voltage Disconnect Under L
350 V
Technical Data Current Disconnect Under Load Usa And Canada
20 A
Technical Data Degree Of Protection According To Canadian Ul Lis
Type 4X / 6P
Technical Data Degree Of Protection According To International E
IP69
Technical Data Maximum Cable Diameter
10 mm
Technical Data Maximum Rated Voltage
600 V
Technical Data Minimum Cable Diameter
6 mm
Technical Data Minimum Rated Voltage
250 V | 400 V
Technical Data Rated Current
20 A
Technical Data Rated Current Canada
15 A
Technical Data Wire Size According To Canadian Standards Associa
16 to 12 AWG
Technical Data Wire Size According To Canadian Ul Listed United
20 to 14 AWG
Technical Data Wire Size According To International Electrotechn
0.50 to 2.5 mm²
