Wieland 2-Pole Light Blue Female Pluggable Electrical Connector - 16A

Name: Wieland 2-Pole Light Blue Female Pluggable Electrical Connector - 16A
Brand: Wieland Electric Inc.
SKU: CIR-92638c
Price: 14.99 USD
Availability: OutOfStock

SKU:CIR-92638c

Reliable Wieland 2-Pole Light Blue Female Electrical Connector - 16A. Ideal for outdoor use.

$14.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The Wieland 2-Pole Light Blue Female Pluggable Electrical Connector is a high-quality solution for outdoor electrical connections. With a rated current of 16A and IP69 protection level, this connector ensures reliable performance in rugged environments. It supports cable diameters ranging from 5mm to 9.5mm and is suitable for voltages up to 600V. Compliant with IEC and cULus wire size standards, this connector is a secure and durable choice for both consumer and institutional applications.

Product Specifications

General Angle Of Plug

Straight

General Brands

Wieland

General Color Of Codingcontact Carrier

Light Blue

General Connection Type

Screw Connection

General Number Of Poles

General Type

Female

Note Note

Technical details are subject to change

Technical Data Alternating Current Ac Voltage Disconnect Under L

300 V

Technical Data Current Disconnect Under Load

16 A

Technical Data Degree Of Protection According To Canadian Ul Lis

Type 4X

Technical Data Degree Of Protection According To International E

IP69

Technical Data Maximum Cable Diameter

9.5 mm

Technical Data Maximum Rated Voltage

600 V

Technical Data Minimum Cable Diameter

5 mm

Technical Data Minimum Rated Voltage

250 V | 400 V

Technical Data Rated Current

16 A

Technical Data Wire Size According To Canadian Ul Listed United

24 to 16 AWG

Technical Data Wire Size According To International Electrotechn

0.25 to 1.5 mmÂ²

Wieland 2-Pole Light Blue Female Pluggable Electrical Connector - 16A
