Wieland 2-Pole Light Gray Circular Female Connector - 20A
Wieland 2-Pole Light Gray Circular Female Connector - 20A
SKU:CIR-e3d0d3
Reliable Wieland 2-Pole Light Gray Female Connector - 20A, IP69 & Type 4X/6P protection, ideal for outdoor use.
Regular price
$24.99
Regular price
Sale price
$24.99
Unit price
per
Initiate Order
Wieland 2-Pole Light Gray Circular Female Connector - 20A
$24.99
Quantity: 1
Claim Your Seller Account
Wieland 2-Pole Light Gray Circular Female Connector - 20A
$24.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland 2-Pole Light Gray Circular Female Connector is a high-quality pluggable electrical connector suitable for various applications. With a straight angle of plug and screw connection, this connector is designed for reliability. It has a maximum cable diameter of 14mm, a rated current of 20A, and a minimum rated voltage of 250V. Meeting IP69 and Type 4X/6P protection standards, this connector ensures durability and safety in outdoor settings. With wire sizes ranging from 0.75 to 6 mm², it complies with international standards, making it ideal for both consumer and institutional use.
Product Specifications
Note Note
Technical details are subject to change
Specifications Angle Of Plug
Straight
Specifications Color Of Codingcontact Carrier
Light Gray
Specifications Connection Type
Screw Connection
Specifications Number Of Poles
2
Specifications Type
Female
Technical Data Alternating Current Ac Voltage Disconnect Under L
350 V
Technical Data Current Disconnect Under Load Usa And Canada
20 A
Technical Data Degree Of Protection According To Canadian Ul Lis
Type 4X / 6P
Technical Data Degree Of Protection According To International E
IP69
Technical Data Maximum Cable Diameter
14 mm
Technical Data Maximum Rated Voltage
600 V
Technical Data Minimum Cable Diameter
10 mm
Technical Data Minimum Rated Voltage
250 V | 400 V
Technical Data Rated Current
20 A
Technical Data Rated Current Canada
15 A
Technical Data Wire Size According To Canadian Standards Associa
16 to 12 AWG
Technical Data Wire Size According To Canadian Ul Listed United
20 to 14 AWG
Technical Data Wire Size According To International Electrotechn
0.50 to 2.5 mm²
