Wieland 2-Pole Male Pluggable Electrical Connector - 16 A (Light Gray)
Wieland 2-Pole Male Pluggable Electrical Connector - 16 A (Light Gray)
SKU:CIR-21c02b
Wieland 2-Pole Male Pluggable Connector - 16A, Light Gray. IP69 & Type 4X rated for outdoor use.
Regular price
$24.99
Regular price
Sale price
$24.99
Unit price
per
Initiate Order
Wieland 2-Pole Male Pluggable Electrical Connector - 16 A (Light Gray)
$24.99
Quantity: 1
Claim Your Seller Account
Wieland 2-Pole Male Pluggable Electrical Connector - 16 A (Light Gray)
$24.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland 2-Pole Male Pluggable Electrical Connector in Light Gray is a robust and reliable solution for outdoor applications. With a straight angle plug and screw connection, this connector supports a rated current of 16 A and a voltage range from 250V to 600V. It meets IP69 and Type 4X protection standards, ensuring durability in harsh environments. Suitable for cable diameters ranging from 5mm to 9.5mm, this connector complies with IEC and cULus wire sizing requirements, making it ideal for various institutional and government procurement needs.
Product Specifications
General Angle Of Plug
Straight
General Brands
Wieland
General Color Of Codingcontact Carrier
Light Gray
General Connection Type
Screw Connection
General Number Of Poles
2
General Type
Male
Note Note
Technical details are subject to change
Technical Data Alternating Current Ac Voltage Disconnect Under L
300 V
Technical Data Current Disconnect Under Load
16 A
Technical Data Degree Of Protection According To Canadian Ul Lis
Type 4X
Technical Data Degree Of Protection According To International E
IP69
Technical Data Maximum Cable Diameter
9.5 mm
Technical Data Maximum Rated Voltage
600 V
Technical Data Minimum Cable Diameter
5 mm
Technical Data Minimum Rated Voltage
250 V | 400 V
Technical Data Rated Current
16 A
Technical Data Wire Size According To Canadian Ul Listed United
24 to 16 AWG
Technical Data Wire Size According To International Electrotechn
0.25 to 1.5 mm²
