Wieland 2-Pole Pebble Gray Female Connector 20A
Wieland 2-Pole Pebble Gray Female Connector 20A
SKU:CIR-e178f3
High-quality 2-Pole connector for outdoor use with secure spring clamp connection. IP69 protection, wide cable diameter range. Meets IEC and cULus standards.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
Wieland 2-Pole Pebble Gray Female Connector 20A
$29.99
Quantity: 1
Claim Your Seller Account
Wieland 2-Pole Pebble Gray Female Connector 20A
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland 2-Pole Pebble Gray Female Connector is a high-quality pluggable electrical connector designed for outdoor use. With a spring clamp connection and IP69 protection, this connector ensures secure and weather-resistant electrical connections. It supports a wide range of cable diameters and voltages, meeting international standards such as IEC and cULus. Trusted by industries requiring reliable electrical solutions.
Product Specifications
Note Note
Technical details are subject to change
Specifications Angle Of Plug
Straight
Specifications Color Of Codingcontact Carrier
Pebble Gray
Specifications Connection Type
Spring Clamp Connection
Specifications Number Of Poles
2
Specifications Type
Female
Technical Data Alternating Current Ac Voltage Disconnect Under L
350 V
Technical Data Current Disconnect Under Load Usa And Canada
20 A
Technical Data Degree Of Protection According To Canadian Ul Lis
Type 4X / 6P
Technical Data Degree Of Protection According To International E
IP69
Technical Data Maximum Cable Diameter
10 mm
Technical Data Maximum Rated Voltage
600 V
Technical Data Minimum Cable Diameter
6 mm
Technical Data Minimum Rated Voltage
250 V | 400 V
Technical Data Rated Current
20 A
Technical Data Rated Current Canada
15 A
Technical Data Wire Size According To Canadian Standards Associa
16 to 12 AWG
Technical Data Wire Size According To Canadian Ul Listed United
20 to 14 AWG
Technical Data Wire Size According To International Electrotechn
0.50 to 2.5 mm²
