Wieland 2-Pole Turquoise Blue Female Pluggable Electrical Connector - 16A
Wieland 2-Pole Turquoise Blue Female Pluggable Electrical Connector - 16A
SKU:CIR-53ea9e
Upgrade to Wieland 2-Pole Turquoise Blue Female Pluggable Electrical Connector - 16A for efficient outdoor connectivity.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
Wieland 2-Pole Turquoise Blue Female Pluggable Electrical Connector - 16A
$29.99
Quantity: 1
Claim Your Seller Account
Wieland 2-Pole Turquoise Blue Female Pluggable Electrical Connector - 16A
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland 2-Pole Turquoise Blue Female Pluggable Electrical Connector is a top-tier solution for robust connections in outdoor environments. Designed to uphold IEC IP69 and cULus Type 4X standards, this connector ensures reliable performance and safety. With a rated voltage up to 600V and a max current of 16A, it accommodates cables from 5mm to 9.5mm in diameter. Compliant with IEC and cULus wire size guidelines, this connector offers seamless screw connections for a secure fit. Upgrade to Wieland for premium quality and durability.
Product Specifications
General Angle Of Plug
Straight
General Brands
Wieland
General Color Of Codingcontact Carrier
Turquoise Blue
General Connection Type
Screw Connection
General Number Of Poles
2
General Type
Female
Note Note
Technical details are subject to change
Technical Data Alternating Current Ac Voltage Disconnect Under L
300 V
Technical Data Current Disconnect Under Load
16 A
Technical Data Degree Of Protection According To Canadian Ul Lis
Type 4X
Technical Data Degree Of Protection According To International E
IP69
Technical Data Maximum Cable Diameter
9.5 mm
Technical Data Maximum Rated Voltage
600 V
Technical Data Minimum Cable Diameter
5 mm
Technical Data Minimum Rated Voltage
250 V | 400 V
Technical Data Rated Current
16 A
Technical Data Wire Size According To Canadian Ul Listed United
24 to 16 AWG
Technical Data Wire Size According To International Electrotechn
0.25 to 1.5 mm²
