Wieland 2 Poles Light Gray Female Connector
Wieland 2 Poles Light Gray Female Connector
SKU:CIR-68c2d3
Reliable 2 Poles Light Gray Female Connector, IP69 and Type 4X / 6P rated, supports up to 20 A current
Regular price
$24.99
Regular price
Sale price
$24.99
Unit price
per
Initiate Order
Wieland 2 Poles Light Gray Female Connector
$24.99
Quantity: 1
Claim Your Seller Account
Wieland 2 Poles Light Gray Female Connector
$24.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland 2 Poles Light Gray Female Connector is a durable and reliable electrical connector designed for outdoor use. With a straight plug angle and spring clamp connection, this connector ensures secure and efficient electrical connections. It supports a rated current of 20 A, making it suitable for a wide range of applications. Meeting IP69 and Type 4X / 6P protection standards, this connector offers outstanding performance in various environments. Suitable for cables ranging from 0.75 to 6 mm² according to IEC standards, it provides flexibility and compatibility for different wiring setups.
Product Specifications
Note Note
Technical details are subject to change
Specifications Angle Of Plug
Straight
Specifications Color Of Codingcontact Carrier
Light Gray
Specifications Connection Type
Spring Clamp Connection
Specifications Number Of Poles
2
Specifications Type
Female
Technical Data Alternating Current Ac Voltage Disconnect Under L
350 V
Technical Data Current Disconnect Under Load Usa And Canada
20 A
Technical Data Degree Of Protection According To Canadian Ul Lis
Type 4X / 6P
Technical Data Degree Of Protection According To International E
IP69
Technical Data Maximum Cable Diameter
10 mm
Technical Data Maximum Rated Voltage
600 V
Technical Data Minimum Cable Diameter
6 mm
Technical Data Minimum Rated Voltage
250 V | 400 V
Technical Data Rated Current
20 A
Technical Data Rated Current Canada
15 A
Technical Data Wire Size According To Canadian Standards Associa
16 to 12 AWG
Technical Data Wire Size According To Canadian Ul Listed United
20 to 14 AWG
Technical Data Wire Size According To International Electrotechn
0.50 to 2.5 mm²
