Wieland 2 Poles Light Gray Female Connector - 20A
Wieland 2 Poles Light Gray Female Connector - 20A
SKU:CIR-e6b4c5
Reliable Wieland 2-Pole Light Gray Female Connector - 20A for outdoor use. Secure spring clamp connection, 600V/20A.
Regular price
$24.99
Regular price
Sale price
$24.99
Unit price
per
Initiate Order
Wieland 2 Poles Light Gray Female Connector - 20A
$24.99
Quantity: 1
Claim Your Seller Account
Wieland 2 Poles Light Gray Female Connector - 20A
$24.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland 2-Pole Female Connector in Light Gray is a high-quality electrical connector designed for outdoor use. Featuring a spring clamp connection, this connector offers a reliable and secure fit for cables ranging from 10mm to 14mm in diameter. With a maximum rated voltage of 600V and a rated current of 20A, this connector meets stringent international standards for electrical safety and performance. Ideal for both consumer and institutional applications, this connector ensures a seamless and durable electrical connection in demanding outdoor environments.
Product Specifications
Note Note
Technical details are subject to change
Specifications Angle Of Plug
Straight
Specifications Color Of Codingcontact Carrier
Light Gray
Specifications Connection Type
Spring Clamp Connection
Specifications Number Of Poles
2
Specifications Type
Female
Technical Data Alternating Current Ac Voltage Disconnect Under L
350 V
Technical Data Current Disconnect Under Load Usa And Canada
20 A
Technical Data Degree Of Protection According To Canadian Ul Lis
Type 4X / 6P
Technical Data Degree Of Protection According To International E
IP69
Technical Data Maximum Cable Diameter
14 mm
Technical Data Maximum Rated Voltage
600 V
Technical Data Minimum Cable Diameter
10 mm
Technical Data Minimum Rated Voltage
250 V | 400 V
Technical Data Rated Current
20 A
Technical Data Rated Current Canada
15 A
Technical Data Wire Size According To Canadian Standards Associa
16 to 12 AWG
Technical Data Wire Size According To Canadian Ul Listed United
20 to 14 AWG
Technical Data Wire Size According To International Electrotechn
0.50 to 2.5 mm²
