Wieland 2-Poles Pebble Gray Female Connector - 20A
Wieland 2-Poles Pebble Gray Female Connector - 20A
SKU:CIR-23ce08
Dependable Wieland 2-Poles Outdoor Connector - IP69 Rated, 10-14mm Cable Diameter, 20A
Regular price
$24.99
Regular price
Sale price
$24.99
Unit price
per
Initiate Order
Wieland 2-Poles Pebble Gray Female Connector - 20A
$24.99
Quantity: 1
Claim Your Seller Account
Wieland 2-Poles Pebble Gray Female Connector - 20A
$24.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland 2-Poles Pebble Gray Female Connector is a top choice for outdoor applications, offering a dependable electrical connection. With a straight angle plug and screw connection, this connector ensures secure installations. Meeting IP69 and Type 4X / 6P standards, it withstands harsh environments. Rated for 250-600V and 20A, compatible with cable diameters 10-14 mm, and wire sizes 0.75-6 mm², this connector exceeds industry requirements.
Product Specifications
Note Note
Technical details are subject to change
Specifications Angle Of Plug
Straight
Specifications Color Of Codingcontact Carrier
Pebble Gray
Specifications Connection Type
Screw Connection
Specifications Number Of Poles
2
Specifications Type
Female
Technical Data Alternating Current Ac Voltage Disconnect Under L
350 V
Technical Data Current Disconnect Under Load Usa And Canada
20 A
Technical Data Degree Of Protection According To Canadian Ul Lis
Type 4X / 6P
Technical Data Degree Of Protection According To International E
IP69
Technical Data Maximum Cable Diameter
14 mm
Technical Data Maximum Rated Voltage
600 V
Technical Data Minimum Cable Diameter
10 mm
Technical Data Minimum Rated Voltage
250 V | 400 V
Technical Data Rated Current
20 A
Technical Data Rated Current Canada
15 A
Technical Data Wire Size According To Canadian Standards Associa
16 to 12 AWG
Technical Data Wire Size According To Canadian Ul Listed United
20 to 14 AWG
Technical Data Wire Size According To International Electrotechn
0.50 to 2.5 mm²
