Wieland 2 Poles Signal Brown Female Connector
Wieland 2 Poles Signal Brown Female Connector
SKU:CIR-d41c5b
High-quality 2 Poles Signal Brown Female Connector by Wieland, ideal for outdoor use. Reliable, waterproof screw connection design, rated 20A, 600V.
Regular price
$24.99
Regular price
Sale price
$24.99
Unit price
per
Initiate Order
Wieland 2 Poles Signal Brown Female Connector
$24.99
Quantity: 1
Claim Your Seller Account
Wieland 2 Poles Signal Brown Female Connector
$24.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland 2 Poles Signal Brown Female Connector is a high-quality pluggable electrical connector suitable for outdoor use. With a straight angle plug design and screw connection, it offers reliable performance. This connector is rated for 20A current, with a maximum voltage of 600V, meeting rigorous international and North American standards for safety and durability. Its IP69 protection rating ensures high resilience against environmental elements. Ideal for applications requiring secure and waterproof connections.
Product Specifications
Note Note
Technical details are subject to change
Specifications Angle Of Plug
Straight
Specifications Color Of Codingcontact Carrier
Signal Brown
Specifications Connection Type
Screw Connection
Specifications Number Of Poles
2
Specifications Type
Female
Technical Data Alternating Current Ac Voltage Disconnect Under L
350 V
Technical Data Current Disconnect Under Load Usa And Canada
20 A
Technical Data Degree Of Protection According To Canadian Ul Lis
Type 4X / 6P
Technical Data Degree Of Protection According To International E
IP69
Technical Data Maximum Cable Diameter
10 mm
Technical Data Maximum Rated Voltage
600 V
Technical Data Minimum Cable Diameter
6 mm
Technical Data Minimum Rated Voltage
250 V | 400 V
Technical Data Rated Current
20 A
Technical Data Rated Current Canada
15 A
Technical Data Wire Size According To Canadian Standards Associa
16 to 12 AWG
Technical Data Wire Size According To Canadian Ul Listed United
20 to 14 AWG
Technical Data Wire Size According To International Electrotechn
0.50 to 2.5 mm²
