Wieland 2 Poles Signal Brown Female Connector
Wieland 2 Poles Signal Brown Female Connector
SKU:CIR-d68bc3
Reliable Wieland 2-Pole Signal Brown Female Connector for outdoor use, ensuring secure connections. Rated 20A, IP69 protection.
Regular price
$28.99
Regular price
Sale price
$28.99
Unit price
per
Initiate Order
Wieland 2 Poles Signal Brown Female Connector
$28.99
Quantity: 1
Claim Your Seller Account
Wieland 2 Poles Signal Brown Female Connector
$28.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland 2 Poles Signal Brown Female Connector is a high-quality pluggable electrical connector designed for outdoor use. With a straight angle plug and spring clamp connection, it ensures secure and reliable connections. Rated for 20 A current, IP69 protection, and compatibility with a wide range of wire sizes, this connector offers durability and versatility for various applications. Suitable for cables ranging from 10 mm to 14 mm in diameter, meeting stringent international electrical standards.
Product Specifications
Note Note
Technical details are subject to change
Specifications Angle Of Plug
Straight
Specifications Color Of Codingcontact Carrier
Signal Brown
Specifications Connection Type
Spring Clamp Connection
Specifications Number Of Poles
2
Specifications Type
Female
Technical Data Alternating Current Ac Voltage Disconnect Under L
350 V
Technical Data Current Disconnect Under Load Usa And Canada
20 A
Technical Data Degree Of Protection According To Canadian Ul Lis
Type 4X / 6P
Technical Data Degree Of Protection According To International E
IP69
Technical Data Maximum Cable Diameter
14 mm
Technical Data Maximum Rated Voltage
600 V
Technical Data Minimum Cable Diameter
10 mm
Technical Data Minimum Rated Voltage
250 V | 400 V
Technical Data Rated Current
20 A
Technical Data Rated Current Canada
15 A
Technical Data Wire Size According To Canadian Standards Associa
16 to 12 AWG
Technical Data Wire Size According To Canadian Ul Listed United
20 to 14 AWG
Technical Data Wire Size According To International Electrotechn
0.50 to 2.5 mm²
