Wieland 24-Pole Heavy-Duty Industrial Connector Housing
Wieland 24-Pole Heavy-Duty Industrial Connector Housing
SKU:IND-218764
Durable Wieland 24-Pole Heavy-Duty Industrial Connector Housing with double locking lever, IP54, RoHS compliant
Regular price
$89.99
Regular price
Sale price
$89.99
Unit price
per
Initiate Order
Wieland 24-Pole Heavy-Duty Industrial Connector Housing
$89.99
Quantity: 1
Claim Your Seller Account
Wieland 24-Pole Heavy-Duty Industrial Connector Housing
$89.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland BOTTOM BAS GUT GE 24 A Multi-Pole Heavy-Duty Industrial Connector Housing is a top-quality solution for industrial applications. Constructed from durable aluminum with a gray powder coating, this housing ensures a reliable connection in demanding environments. Featuring a double locking lever, protective cover, and IP54 rating, it provides secure and weather-resistant protection. With a temperature range from -40°C to 120°C, it offers versatility and performance. This 24-pole connector housing meets RoHS compliance and is lead-free, making it a sustainable choice for your projects.
Product Specifications
Classification Eclass 81 Classification
27440202
Classification Etim 30 Classification
EC000437
Classification Etim 40 Classification
EC000437
Classification Etim 50 Classification
EC000437
Classification Etim 60 Classification
EC000437
Classification Etim 70 Classification
EC000437
General Brands
Wieland
General Color
Gray
General Degree Of Protection Ip
IP54
General Housing Material
Aluminum
General Inflammability Class Of Insulation Material According Wi
Other
General Maximum Operating Temperature Range
120 ºC
General Minimum Operating Temperature Range
-40 ºC
General Model
BOTTOM BAS GUT GE 24 A
General Surface
With Powder Coating
General Ultraviolet Uv Resistant
Yes
Model Cable Entry
None
Model Construction
24
Model Emc Version
No
Model Height
28 mm
Model Hinged Lid
Yes
Model Length
140 mm
Model Locking Mechanism
Double Locking Levers
Model Type
Equipment Mounted (Feed-Through)
Model Type Of Cable
None
Model Width
44 mm
Model With Cable Screw Gland
No
Product Compliance Reach Svhc Cas Numbers
7439-92-1
Product Compliance Reach Svhc Conformity Status
Duty-To-Declare
Product Compliance Reach Svhc Substances
Lead
Product Compliance Rohs Conformity Status
Compliant with Exceptions
Product Compliance Rohs Exceptions
III-6(a)
Specifications Number Of Poles
24
Specifications Profile
Low
