Wieland 24DC-1W-250V6A Screw Clamp Relay Module
Wieland 24DC-1W-250V6A Screw Clamp Relay Module
SKU:COU-1beec8
Reliable Wieland 24DC-1W-250V6A Relay Module for industrial use. 1 change-over contact, 24V DC input, 250V AC/6A output. RoHS & REACH-SVHC compliant.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
Wieland 24DC-1W-250V6A Screw Clamp Relay Module
$29.99
Quantity: 1
Claim Your Seller Account
Wieland 24DC-1W-250V6A Screw Clamp Relay Module
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland 24DC-1W-250V6A Relay Module is a reliable coupling relay designed for industrial applications. With one change-over contact, screw clamp terminals, and a compact width of 6.2mm, this module ensures secure connections. Operating at 24V DC input and 250V AC/6A output, it provides efficient control signal switching. The module is compliant with RoHS and REACH-SVHC standards, offering peace of mind regarding environmental regulations and product safety.
Product Specifications
Classification Eclass 81 Classification
27371601
Classification Etim 30 Classification
EC001437
Classification Etim 40 Classification
EC001437
Classification Etim 50 Classification
EC001437
Classification Etim 60 Classification
EC001437
Classification Etim 70 Classification
EC001437
Dimensions Depth
70 mm
Dimensions Height
89 mm
Dimensions Width
6.2 mm
General Brands
Wieland
General Complete With Socket
Yes
General Connection Type
Screw Connection
General Degree Of Protection Ip
IP20
General Detachable Clamps
No
General Forced Guided Contacts
No
General Function Drive
Mono Stable
General Model
RELAY MODULE FLARE-24DC-1W-250V6A
General Number Of Change Over Contacts
1
General Polarization Drive
Polarity Free
Product Compliance Reach Svhc Conformity Status
Compliant
Product Compliance Rohs Conformity Status
Compliant
Technical Data Direct Current Dc Lower Nominal Voltage
19.2 V
Technical Data Direct Current Dc Upper Nominal Voltage
30 V
Technical Data Minimum Direct Current Dc Nominal Voltage
24 V
Technical Data Type Of Excitation
Direct Current (DC)
