Wieland 24V-1W-48V20M Relay Module

Wieland 24V-1W-48V20M Relay Module

SKU:COU-78cf8c

High-quality Wieland 24V-1W-48V20M Relay Module for secure and efficient operations. Compatible with 24VAC/DC input and 48V/20mA output. IP20 protection. RoHS and REACH-SVHC compliant.

Regular price $39.99
Regular price Sale price $39.99
Sale

Initiate Order

Wieland 24V-1W-48V20M Relay Module

Wieland 24V-1W-48V20M Relay Module

$39.99

Quantity: 1

Claim Your Seller Account

Wieland 24V-1W-48V20M Relay Module

Wieland 24V-1W-48V20M Relay Module

$39.99

Quantity: 1

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details
The Wieland 24V-1W-48V20M Relay Module is a high-quality coupling relay with a 6.2mm overall width. It features 1 change-over contact with screw connections for reliable input/output. This relay module is designed for compatibility with 24VAC/DC input and 48V/20mA output, offering gold-plated voltage/current contacts. With a compact design and IP20 protection, it ensures secure and efficient operation. Compliant with RoHS and REACH-SVHC standards, this relay module meets essential environmental regulations for sustainable procurement.

Product Specifications

Classification Eclass 81 Classification
27371601
Classification Etim 30 Classification
EC001437
Classification Etim 40 Classification
EC001437
Classification Etim 50 Classification
EC001437
Classification Etim 60 Classification
EC001437
Classification Etim 70 Classification
EC001437
Dimensions Depth
70 mm
Dimensions Height
89 mm
Dimensions Width
6.2 mm
General Brands
Wieland
General Complete With Socket
Yes
General Connection Type
Screw Connection
General Degree Of Protection Ip
IP20
General Detachable Clamps
No
General Forced Guided Contacts
No
General Function Drive
Mono Stable
General Model
RELAY MODULE FLARE-24V-1W-48V20M
General Number Of Change Over Contacts
1
General Polarization Drive
Polarity Free
Product Compliance Reach Svhc Conformity Status
Compliant
Product Compliance Rohs Conformity Status
Compliant
Technical Data Direct Current Dc Lower Nominal Voltage
19.2 V
Technical Data Direct Current Dc Upper Nominal Voltage
30 V
Technical Data Minimum Direct Current Dc Nominal Voltage
24 V
Technical Data Type Of Excitation
Direct Current (DC)
