Wieland 3-Pole Light Blue Male Connector
Wieland 3-Pole Light Blue Male Connector
SKU:CIR-594151
High-quality outdoor 3-Pole Light Blue Male Connector for secure and reliable electrical connections in demanding applications.
Regular price
$24.99
Regular price
Sale price
$24.99
Unit price
per
Initiate Order
Wieland 3-Pole Light Blue Male Connector
$24.99
Quantity: 1
Claim Your Seller Account
Wieland 3-Pole Light Blue Male Connector
$24.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland 3-Pole Light Blue Male Connector is a high-quality, pluggable electrical connector suitable for outdoor use. With a straight angle plug and spring clamp connection, it offers a secure and reliable connection. This connector supports a rated current of 20 A, making it ideal for demanding electrical applications. It is designed to accommodate cables ranging from 13mm to 18mm in diameter and meets IP69 and Type 4X / 6P protection standards, ensuring durability in harsh environments.
Product Specifications
Note Note
Technical details are subject to change
Specifications Angle Of Plug
Straight
Specifications Color Of Codingcontact Carrier
Light Blue
Specifications Connection Type
Spring Clamp Connection
Specifications Number Of Poles
3
Specifications Type
Male
Technical Data Alternating Current Ac Voltage Disconnect Under L
350 V
Technical Data Current Disconnect Under Load Usa And Canada
20 A
Technical Data Degree Of Protection According To Canadian Ul Lis
Type 4X / 6P
Technical Data Degree Of Protection According To International E
IP69
Technical Data Maximum Cable Diameter
18 mm
Technical Data Maximum Rated Voltage
600 V
Technical Data Minimum Cable Diameter
13 mm
Technical Data Minimum Rated Voltage
250 V | 400 V
Technical Data Rated Current
20 A
Technical Data Rated Current Canada
15 A
Technical Data Wire Size According To Canadian Standards Associa
16 to 12 AWG
Technical Data Wire Size According To Canadian Ul Listed United
20 to 14 AWG
Technical Data Wire Size According To International Electrotechn
0.50 to 2.5 mm²
