Wieland 3-Pole Light Blue Male Connector - 20A Pluggable Circular Electrical Connector
Wieland 3-Pole Light Blue Male Connector - 20A Pluggable Circular Electrical Connector
SKU:CIR-b2cba7
Reliable Wieland 3-Pole Light Blue Male Connector - 20A for secure outdoor electrical connections
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
Wieland 3-Pole Light Blue Male Connector - 20A Pluggable Circular Electrical Connector
$29.99
Quantity: 1
Claim Your Seller Account
Wieland 3-Pole Light Blue Male Connector - 20A Pluggable Circular Electrical Connector
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland 3-Pole Light Blue Male Connector is designed for robust outdoor use, featuring a straight angle plug with a spring clamp connection. With a rated current of 20A and IP69 protection according to IEC standards, this connector is suitable for voltage requirements ranging from 250V to 600V. Its versatility in accommodating cable diameters from 10mm to 14mm, along with compatibility with various wire sizes per IEC and cULus guidelines, ensures reliable and secure electrical connections for both consumer and institutional applications.
Product Specifications
Note Note
Technical details are subject to change
Specifications Angle Of Plug
Straight
Specifications Color Of Codingcontact Carrier
Light Blue
Specifications Connection Type
Spring Clamp Connection
Specifications Number Of Poles
3
Specifications Type
Male
Technical Data Alternating Current Ac Voltage Disconnect Under L
350 V
Technical Data Current Disconnect Under Load Usa And Canada
20 A
Technical Data Degree Of Protection According To Canadian Ul Lis
Type 4X / 6P
Technical Data Degree Of Protection According To International E
IP69
Technical Data Maximum Cable Diameter
14 mm
Technical Data Maximum Rated Voltage
600 V
Technical Data Minimum Cable Diameter
10 mm
Technical Data Minimum Rated Voltage
250 V | 400 V
Technical Data Rated Current
20 A
Technical Data Rated Current Canada
15 A
Technical Data Wire Size According To Canadian Standards Associa
16 to 12 AWG
Technical Data Wire Size According To Canadian Ul Listed United
20 to 14 AWG
Technical Data Wire Size According To International Electrotechn
0.50 to 2.5 mm²
