Wieland 3-Pole Light Blue Male Pluggable Electrical Connector - 16 A
Wieland 3-Pole Light Blue Male Pluggable Electrical Connector - 16 A
SKU:CIR-3d8135
Reliable Wieland 3-Pole Light Blue Male Pluggable Connector - 16 A for outdoor use, IP69 protection, meets IEC and cULus standards.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
Wieland 3-Pole Light Blue Male Pluggable Electrical Connector - 16 A
$29.99
Quantity: 1
Claim Your Seller Account
Wieland 3-Pole Light Blue Male Pluggable Electrical Connector - 16 A
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland 3-Pole Light Blue Male Pluggable Electrical Connector is designed for robust outdoor applications. With a maximum rated current of 16 A and IP69-rated protection, this connector ensures reliable power transmission. Meeting IEC and cULus standards for wire sizes and voltages, it offers a secure screw connection for cables ranging from 5mm to 9.5mm in diameter. Stay connected with confidence in demanding environments.
Product Specifications
General Angle Of Plug
Straight
General Brands
Wieland
General Color Of Codingcontact Carrier
Light Blue
General Connection Type
Screw Connection
General Number Of Poles
3
General Type
Male
Note Note
Technical details are subject to change
Technical Data Alternating Current Ac Voltage Disconnect Under L
300 V
Technical Data Current Disconnect Under Load
16 A
Technical Data Degree Of Protection According To Canadian Ul Lis
Type 4X
Technical Data Degree Of Protection According To International E
IP69
Technical Data Maximum Cable Diameter
9.5 mm
Technical Data Maximum Rated Voltage
600 V
Technical Data Minimum Cable Diameter
5 mm
Technical Data Minimum Rated Voltage
250 V | 400 V
Technical Data Rated Current
16 A
Technical Data Wire Size According To Canadian Ul Listed United
24 to 16 AWG
Technical Data Wire Size According To International Electrotechn
0.25 to 1.5 mm²
