Wieland 3-Pole Light Gray Female Connector
Wieland 3-Pole Light Gray Female Connector
SKU:CIR-f03cdb
Reliable Wieland 3-Pole Light Gray Female Connector for secure outdoor electrical connections. Rated 20 A with IP69 protection.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
Wieland 3-Pole Light Gray Female Connector
$29.99
Quantity: 1
Claim Your Seller Account
Wieland 3-Pole Light Gray Female Connector
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland 3-Pole Light Gray Female Connector is a high-quality pluggable electrical connector designed for outdoor use. With a spring clamp connection, it ensures secure and reliable electrical connections. This connector is rated for 20 A current, suitable for various applications. It meets IP69 and Type 4X/6P standards, ensuring durability and protection against environmental factors. With a wide acceptable cable diameter range and compatibility with different wire sizes, it offers flexibility and ease of installation.
Product Specifications
Note Note
Technical details are subject to change
Specifications Angle Of Plug
Straight
Specifications Color Of Codingcontact Carrier
Light Gray
Specifications Connection Type
Spring Clamp Connection
Specifications Number Of Poles
3
Specifications Type
Female
Technical Data Alternating Current Ac Voltage Disconnect Under L
350 V
Technical Data Current Disconnect Under Load Usa And Canada
20 A
Technical Data Degree Of Protection According To Canadian Ul Lis
Type 4X / 6P
Technical Data Degree Of Protection According To International E
IP69
Technical Data Maximum Cable Diameter
18 mm
Technical Data Maximum Rated Voltage
600 V
Technical Data Minimum Cable Diameter
13 mm
Technical Data Minimum Rated Voltage
250 V | 400 V
Technical Data Rated Current
20 A
Technical Data Rated Current Canada
15 A
Technical Data Wire Size According To Canadian Standards Associa
16 to 12 AWG
Technical Data Wire Size According To Canadian Ul Listed United
20 to 14 AWG
Technical Data Wire Size According To International Electrotechn
0.50 to 2.5 mm²
