Wieland 3-Pole Light Gray Female Electrical Connector 20A
Wieland 3-Pole Light Gray Female Electrical Connector 20A
SKU:CIR-fb1e39
Reliable Wieland 3-Pole Light Gray Female Connector for secure electrical connections. IP69 rated for outdoor use. Rated current 20A.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
Wieland 3-Pole Light Gray Female Electrical Connector 20A
$29.99
Quantity: 1
Claim Your Seller Account
Wieland 3-Pole Light Gray Female Electrical Connector 20A
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Experience reliable and secure electrical connections with the Wieland 3-Pole Light Gray Female Electrical Connector. This pluggable connector features a straight angle plug design, screw connection type, and an IP69 protection rating ensuring superior performance in outdoor settings. With a rated current of 20A and compatibility with various wire sizes, this connector meets stringent electrical standards for high-voltage applications.
Product Specifications
Note Note
Technical details are subject to change
Specifications Angle Of Plug
Straight
Specifications Color Of Codingcontact Carrier
Light Gray
Specifications Connection Type
Screw Connection
Specifications Number Of Poles
3
Specifications Type
Female
Technical Data Alternating Current Ac Voltage Disconnect Under L
350 V
Technical Data Current Disconnect Under Load Usa And Canada
20 A
Technical Data Degree Of Protection According To Canadian Ul Lis
Type 4X / 6P
Technical Data Degree Of Protection According To International E
IP69
Technical Data Maximum Cable Diameter
18 mm
Technical Data Maximum Rated Voltage
600 V
Technical Data Minimum Cable Diameter
13 mm
Technical Data Minimum Rated Voltage
250 V | 400 V
Technical Data Rated Current
20 A
Technical Data Rated Current Canada
15 A
Technical Data Wire Size According To Canadian Standards Associa
16 to 12 AWG
Technical Data Wire Size According To Canadian Ul Listed United
20 to 14 AWG
Technical Data Wire Size According To International Electrotechn
0.50 to 2.5 mm²
