Wieland 3-Pole Light Gray Male Connector

Name: Wieland 3-Pole Light Gray Male Connector
Brand: Wieland Electric Inc.
SKU: CIR-8fd0f1
Price: 29.99 USD
Availability: OutOfStock

SKU:CIR-8fd0f1

Top-quality 3-Pole Light Gray Male Connector with 20A rated current, ideal for outdoor use.

$29.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The Wieland 3-Pole Light Gray Male Connector is a top-quality pluggable electrical connector suitable for outdoor applications. With a straight angle plug and screw connection, this connector ensures secure and reliable connections. It features a rated current of 20A, accommodating cable diameters from 13mm to 18mm. Meeting IP69 and Type 4X/6P protection standards, this connector guarantees safety and durability in challenging environments.

Product Specifications

Note Note

Technical details are subject to change

Specifications Angle Of Plug

Straight

Specifications Color Of Codingcontact Carrier

Light Gray

Specifications Connection Type

Screw Connection

Specifications Number Of Poles

Specifications Type

Male

Technical Data Alternating Current Ac Voltage Disconnect Under L

350 V

Technical Data Current Disconnect Under Load Usa And Canada

20 A

Technical Data Degree Of Protection According To Canadian Ul Lis

Type 4X / 6P

Technical Data Degree Of Protection According To International E

IP69

Technical Data Maximum Cable Diameter

18 mm

Technical Data Maximum Rated Voltage

600 V

Technical Data Minimum Cable Diameter

13 mm

Technical Data Minimum Rated Voltage

250 V | 400 V

Technical Data Rated Current

20 A

Technical Data Rated Current Canada

15 A

Technical Data Wire Size According To Canadian Standards Associa

16 to 12 AWG

Technical Data Wire Size According To Canadian Ul Listed United

20 to 14 AWG

Technical Data Wire Size According To International Electrotechn

0.50 to 2.5 mmÂ²

Wieland 3-Pole Light Gray Male Connector
