Wieland 3-Pole Light Gray Male Electrical Connector, 20A
Wieland 3-Pole Light Gray Male Electrical Connector, 20A
SKU:CIR-b95326
High-quality 3-pole male electrical connector with straight angle plug, spring clamp connection, and IP69 protection. Reliable and compliant with international standards.
Regular price
$24.99
Regular price
Sale price
$24.99
Unit price
per
Initiate Order
Wieland 3-Pole Light Gray Male Electrical Connector, 20A
$24.99
Quantity: 1
Claim Your Seller Account
Wieland 3-Pole Light Gray Male Electrical Connector, 20A
$24.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland 3-Pole Light Gray Male Connector is a high-quality pluggable electrical connector designed for both indoor and outdoor use. Featuring a straight angle plug and spring clamp connection, this connector ensures easy and secure wiring. With a minimum cable diameter of 10 mm and a maximum rated voltage of 600V, it is suitable for various applications. Meeting IP69 and Type 4X/6P protection standards, this connector is durable and reliable. Compliant with IEC, cULus, and CSA wire size standards, it offers compatibility and safety. Upgrade your electrical connections with this robust and versatile male connector.
Product Specifications
Note Note
Technical details are subject to change
Specifications Angle Of Plug
Straight
Specifications Color Of Codingcontact Carrier
Light Gray
Specifications Connection Type
Spring Clamp Connection
Specifications Number Of Poles
3
Specifications Type
Male
Technical Data Alternating Current Ac Voltage Disconnect Under L
350 V
Technical Data Current Disconnect Under Load Usa And Canada
20 A
Technical Data Degree Of Protection According To Canadian Ul Lis
Type 4X / 6P
Technical Data Degree Of Protection According To International E
IP69
Technical Data Maximum Cable Diameter
14 mm
Technical Data Maximum Rated Voltage
600 V
Technical Data Minimum Cable Diameter
10 mm
Technical Data Minimum Rated Voltage
250 V | 400 V
Technical Data Rated Current
20 A
Technical Data Rated Current Canada
15 A
Technical Data Wire Size According To Canadian Standards Associa
16 to 12 AWG
Technical Data Wire Size According To Canadian Ul Listed United
20 to 14 AWG
Technical Data Wire Size According To International Electrotechn
0.50 to 2.5 mm²
