The Wieland 3-Pole Male Pluggable Electrical Connector is a reliable solution for outdoor electrical connections. With a straight angle plug design and light gray color for easy identification, this connector offers secure screw connections suitable for cables ranging from 5mm to 9.5mm in diameter. It's rated for voltages up to 600V and currents up to 16A, meeting international standards like IP69 and offering compatibility with wire sizes from 0.25 to 1.5 mm² (IEC) or 24 to 16 AWG (cULus). Stay connected with confidence and durability in any outdoor setting.
Product Specifications
General Angle Of Plug
Straight
General Brands
Wieland
General Color Of Codingcontact Carrier
Light Gray
General Connection Type
Screw Connection
General Number Of Poles
3
General Type
Male
Note Note
Technical details are subject to change
Technical Data Alternating Current Ac Voltage Disconnect Under L
300 V
Technical Data Current Disconnect Under Load
16 A
Technical Data Degree Of Protection According To Canadian Ul Lis
Type 4X
Technical Data Degree Of Protection According To International E
IP69
Technical Data Maximum Cable Diameter
9.5 mm
Technical Data Maximum Rated Voltage
600 V
Technical Data Minimum Cable Diameter
5 mm
Technical Data Minimum Rated Voltage
250 V | 400 V
Technical Data Rated Current
16 A
Technical Data Wire Size According To Canadian Ul Listed United
24 to 16 AWG
Technical Data Wire Size According To International Electrotechn
0.25 to 1.5 mm²
