Wieland 3 Poles Light Blue Female Connector 20A
Wieland 3 Poles Light Blue Female Connector 20A
SKU:CIR-a50142
High-quality Wieland 3 Poles Light Blue Female Connector for secure outdoor electrical connections. IP69 rated.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
Wieland 3 Poles Light Blue Female Connector 20A
$29.99
Quantity: 1
Claim Your Seller Account
Wieland 3 Poles Light Blue Female Connector 20A
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland 3 Poles Light Blue Female Connector is a high-quality pluggable electrical connector suitable for outdoor use. With a straight plug design and screw connection, this connector ensures secure and reliable electrical connections. It features a light blue color coding for easy identification and can accommodate cables with diameters ranging from 13mm to 18mm. Rated for voltages up to 600V and a current of 20A, this connector meets stringent international standards like IP69 for protection against dust and water. Ideal for institutional and government procurement due to its robust construction and reliable performance.
Product Specifications
Note Note
Technical details are subject to change
Specifications Angle Of Plug
Straight
Specifications Color Of Codingcontact Carrier
Light Blue
Specifications Connection Type
Screw Connection
Specifications Number Of Poles
3
Specifications Type
Female
Technical Data Alternating Current Ac Voltage Disconnect Under L
350 V
Technical Data Current Disconnect Under Load Usa And Canada
20 A
Technical Data Degree Of Protection According To Canadian Ul Lis
Type 4X / 6P
Technical Data Degree Of Protection According To International E
IP69
Technical Data Maximum Cable Diameter
18 mm
Technical Data Maximum Rated Voltage
600 V
Technical Data Minimum Cable Diameter
13 mm
Technical Data Minimum Rated Voltage
250 V | 400 V
Technical Data Rated Current
20 A
Technical Data Rated Current Canada
15 A
Technical Data Wire Size According To Canadian Standards Associa
16 to 12 AWG
Technical Data Wire Size According To Canadian Ul Listed United
20 to 14 AWG
Technical Data Wire Size According To International Electrotechn
0.50 to 2.5 mm²
