Wieland 3 Poles Light Blue Male Connector - 20 A, Outdoor Rated
Wieland 3 Poles Light Blue Male Connector - 20 A, Outdoor Rated
SKU:CIR-7ed20e
Secure outdoor electrical connections with Wieland 3 Poles Light Blue Male Connector. IP69 rated, 20 A capacity for reliable performance.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
Wieland 3 Poles Light Blue Male Connector - 20 A, Outdoor Rated
$29.99
Quantity: 1
Claim Your Seller Account
Wieland 3 Poles Light Blue Male Connector - 20 A, Outdoor Rated
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland 3 Poles Light Blue Male Connector is designed for heavy-duty electrical connections. With a straight angle plug and screw connection, it ensures secure and reliable performance in outdoor settings. This connector supports a rated current of 20 A, meets international standards for IP69 protection, and accommodates cable diameters ranging from 10mm to 14mm. Ideal for applications requiring robust and weather-resistant electrical connectivity.
Product Specifications
Note Note
Technical details are subject to change
Specifications Angle Of Plug
Straight
Specifications Color Of Codingcontact Carrier
Light Blue
Specifications Connection Type
Screw Connection
Specifications Number Of Poles
3
Specifications Type
Male
Technical Data Alternating Current Ac Voltage Disconnect Under L
350 V
Technical Data Current Disconnect Under Load Usa And Canada
20 A
Technical Data Degree Of Protection According To Canadian Ul Lis
Type 4X / 6P
Technical Data Degree Of Protection According To International E
IP69
Technical Data Maximum Cable Diameter
14 mm
Technical Data Maximum Rated Voltage
600 V
Technical Data Minimum Cable Diameter
10 mm
Technical Data Minimum Rated Voltage
250 V | 400 V
Technical Data Rated Current
20 A
Technical Data Rated Current Canada
15 A
Technical Data Wire Size According To Canadian Standards Associa
16 to 12 AWG
Technical Data Wire Size According To Canadian Ul Listed United
20 to 14 AWG
Technical Data Wire Size According To International Electrotechn
0.50 to 2.5 mm²
