Wieland 3 Poles Light Gray Male Connector - 20A
Wieland 3 Poles Light Gray Male Connector - 20A
SKU:CIR-cdee76
High-quality Wieland 3 Poles Male Connector - 20A for secure outdoor electrical connections. IP69 rated, compliant with international standards.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
Wieland 3 Poles Light Gray Male Connector - 20A
$29.99
Quantity: 1
Claim Your Seller Account
Wieland 3 Poles Light Gray Male Connector - 20A
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland 3 Poles Light Gray Male Connector features a straight angle plug and spring clamp connection, suitable for outdoor use with IP69 protection. Rated for 20A, 600V, it accommodates cables from 0.75 to 6mm² according to IEC standards. With a durable design, this connector ensures secure and reliable electrical connections, meeting stringent industry standards like Type 4X / 6P.
Product Specifications
Note Note
Technical details are subject to change
Specifications Angle Of Plug
Straight
Specifications Color Of Codingcontact Carrier
Light Gray
Specifications Connection Type
Spring Clamp Connection
Specifications Number Of Poles
3
Specifications Type
Male
Technical Data Alternating Current Ac Voltage Disconnect Under L
350 V
Technical Data Current Disconnect Under Load Usa And Canada
20 A
Technical Data Degree Of Protection According To Canadian Ul Lis
Type 4X / 6P
Technical Data Degree Of Protection According To International E
IP69
Technical Data Maximum Cable Diameter
10 mm
Technical Data Maximum Rated Voltage
600 V
Technical Data Minimum Cable Diameter
6 mm
Technical Data Minimum Rated Voltage
250 V | 400 V
Technical Data Rated Current
20 A
Technical Data Rated Current Canada
15 A
Technical Data Wire Size According To Canadian Standards Associa
16 to 12 AWG
Technical Data Wire Size According To Canadian Ul Listed United
20 to 14 AWG
Technical Data Wire Size According To International Electrotechn
0.50 to 2.5 mm²
