Wieland 3 Poles Pluggable Male Connector - Light Blue
Wieland 3 Poles Pluggable Male Connector - Light Blue
SKU:CIR-a4f393
High-quality Wieland 3-Pole Male Connector for outdoor electrical connections. IP69 protection, wide cable compatibility, and robust design.
Regular price
$24.99
Regular price
Sale price
$24.99
Unit price
per
Initiate Order
Wieland 3 Poles Pluggable Male Connector - Light Blue
$24.99
Quantity: 1
Claim Your Seller Account
Wieland 3 Poles Pluggable Male Connector - Light Blue
$24.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland 3 Poles Light Blue Color Male Connector is a top-quality electrical connector designed for industrial applications. With a straight angle plug, screw connection, and IP69 protection level, this connector ensures reliable performance in outdoor settings. It supports a wide range of cable diameters, rated currents, and voltages, meeting international standards for safety and durability. Ideal for outdoor electrical connections requiring a robust and weather-resistant solution.
Product Specifications
Note Note
Technical details are subject to change
Specifications Angle Of Plug
Straight
Specifications Color Of Codingcontact Carrier
Light Blue
Specifications Connection Type
Screw Connection
Specifications Number Of Poles
3
Specifications Type
Male
Technical Data Alternating Current Ac Voltage Disconnect Under L
350 V
Technical Data Current Disconnect Under Load Usa And Canada
20 A
Technical Data Degree Of Protection According To Canadian Ul Lis
Type 4X / 6P
Technical Data Degree Of Protection According To International E
IP69
Technical Data Maximum Cable Diameter
10 mm
Technical Data Maximum Rated Voltage
600 V
Technical Data Minimum Cable Diameter
6 mm
Technical Data Minimum Rated Voltage
250 V | 400 V
Technical Data Rated Current
20 A
Technical Data Rated Current Canada
15 A
Technical Data Wire Size According To Canadian Standards Associa
16 to 12 AWG
Technical Data Wire Size According To Canadian Ul Listed United
20 to 14 AWG
Technical Data Wire Size According To International Electrotechn
0.50 to 2.5 mm²
