The Wieland 4.3-inch Diagonal HMI Panel is a robust Human-Machine Interface solution designed for industrial environments. Featuring a TFT Thin Film Transistor display with LED backlight, this panel offers a resolution of 480x272 pixels and 16-bit color depth. With IP66 protection and a wide operating temperature range from -10°C to 60°C, it ensures reliable performance in diverse conditions. Equipped with Modbus TCP support, Ethernet connectivity, and 64MB RAM, it enables seamless integration and control. The panel is programmable using hmiPLAN software, making it an efficient choice for controlling automation processes.
Product Specifications
Accessories Accessories
Part NumberHMI-Plan License (ZW.000.0170.0)DescriptionSingle-user license for hmiPLAN, configuration software for HMI applications and visualizationClassificationECLASS 11 - 27242592ECLASS 8.1 - 27249209ETIM 9.0 - EC002584ETIM 8.0 - EC002584ETIM 7.0 - EC002584ETIM 6.0 - EC002584ETIM 5.0 - EC002584ETIM 4.0 - EC002584
Classification Eclass 81 Classification
27242301
Classification Etim 40 Classification
EC001414
Classification Etim 50 Classification
EC001414
Classification Etim 60 Classification
EC001414
Classification Etim 70 Classification
EC001414
Dimensions Build In Depth
33 m
Dimensions Cutout Height
92.5 mm
Dimensions Cutout Width
118.5 mm
Dimensions Height Of The Front
103 mm
Dimensions Weight
230 g
Dimensions Width Of The Front
129 mm
Display Backlight Life
20000 h
Display Central Processing Unit Cpu Type
RISC ARM9 32 Bit
Display Maximum Colors
16 Bit
Display Number Of Horizontal Pixels
480
Display Number Of Vertical Pixels
272
Display Screen Diagonal
4.3 in
Display Touch Technology
Resistive Touch
Display Type Of Display
Thin Film Transistor (TFT) Colour Liquid Crystal Display (LCD) with Light Emitting Diode (LED) Backlight
Product Compliance Reach Svhc Conformity Status
Compliant
Product Compliance Rohs Conformity Status
Compliant with Exceptions
Product Compliance Rohs Exceptions
III-6(a);Â III-6(c);Â III-7(a);Â III-7(c)I
Specifications Model
HMI-ECO-043
Supply Circuit Direct Current Dc Rated Consumption
10 W
Supply Circuit Maximum Rated Supply Voltage At Direct Current Dc
26.4 V
Supply Circuit Minimum Rated Supply Voltage At Direct Current Dc
21.6 V
Supply Circuit Voltage Type
Direct Current (DC)
Technical Data Approvals
Yes
Technical Data Battery Backed Ram
Yes
Technical Data Compatible Plc Families
Allen Bradley | Beckhoff | Schneider | Siemens | u.v.a. | Wago
Technical Data Cooling
Natural Cooling with Minimum 50 mm Distance to Environment
Technical Data Degree Of Protection Ip
IP66
Technical Data Degree Of Protection Nema
4X
Technical Data Emi
FCC Part 15 Class A
Technical Data Ethernet Protocols
ADS for TwinCAT3 | Ethernet IP | Modbus TCP Master | Modbus TCP Slave | u.v.a.
Technical Data Font Type
ASCII (Europ front type) | Chinese (Simple Chinese) | Japanese (ANK, Kanji) | Korean | Kyrilic | Taiwanese (Traditional Chinese)
Technical Data Maximum Main Memory
64 MB
Technical Data Power Supply Type
SELV (UL 508, UL 248)
