Wieland 4 and 5 Poles Light Gray Distributor Block
Wieland 4 and 5 Poles Light Gray Distributor Block
SKU:CIR-010810
Reliable Wieland Distributor Block for efficient electrical distribution, IP69 protection, and high voltage compatibility up to 600V.
Regular price
$34.99
Regular price
Sale price
$34.99
Unit price
per
Initiate Order
Wieland 4 and 5 Poles Light Gray Distributor Block
$34.99
Quantity: 1
Claim Your Seller Account
Wieland 4 and 5 Poles Light Gray Distributor Block
$34.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Experience efficient electrical distribution with the Wieland 4 and 5 Poles Distributor Block in a sleek light gray color. This circular electrical connector offers flexible cable diameter compatibility from 7.1 to 13mm and meets high voltage standards of up to 600V. With a sturdy construction and IP69 protection, this block ensures reliable parallel connections while allowing fastening to mounting plates. Rated for 16A current and suitable for wire sizes ranging from 0.25 to 2.5mm² or 22 to 16 AWG per cULus standards, this model provides a secure and durable solution for various applications. Stay ahead with Wieland's trusted quality and performance.
Product Specifications
General Brands
Wieland
General Color Of Codingcontact Carrier
Light Gray
Model Number Of Inputs
1
Model Number Of Outputs
2
Note Note
Technical details are subject to change
Technical Data Alternating Current Ac Voltage Disconnect Under L
350 V
Technical Data Cable Diameter
7.1 to 13 mm
Technical Data Current Disconnect Under Load
16 A
Technical Data Degree Of Protection According To Canadian Ul Lis
Type 4X / 6P
Technical Data Degree Of Protection According To International E
IP69
Technical Data Maximum Rated Voltage
600 V
Technical Data Minimum Rated Voltage
250 V | 400 V
Technical Data Number Of Poles
4 | 5
Technical Data Rated Current
16 A
Technical Data Wire Size According To Canadian Ul Listed United
22 to 16 AWG
Technical Data Wire Size According To International Electrotechn
0.25 to 2.5 mm²
