Wieland 40-Pole Aluminum Industrial Multi-Pole Connector Housing
Wieland 40-Pole Aluminum Industrial Multi-Pole Connector Housing
SKU:IND-730520
Durable Wieland multi-pole connector housing with aluminum construction, single locking lever, and RoHS compliance.
Regular price
$69.99
Regular price
Sale price
$69.99
Unit price
per
Initiate Order
Wieland 40-Pole Aluminum Industrial Multi-Pole Connector Housing
$69.99
Quantity: 1
Claim Your Seller Account
Wieland 40-Pole Aluminum Industrial Multi-Pole Connector Housing
$69.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland HOOD BAS GOT GG 40HM40 50 A1 Multi-Pole Heavy-Duty Industrial Connector Housing is designed for industrial applications requiring durability and reliability. Constructed from aluminum with a powder coating, this housing ensures long-lasting performance. Featuring a single locking lever, M40 threaded hole, and a low profile design, it provides secure connections. With a temperature range of -40°C to 120°C, UV resistance, and compliance with RoHS standards, this connector housing is ideal for demanding environments.
Product Specifications
Classification Eclass 81 Classification
27440202
Classification Etim 30 Classification
EC000437
Classification Etim 40 Classification
EC000437
Classification Etim 50 Classification
EC000437
Classification Etim 60 Classification
EC000437
Classification Etim 70 Classification
EC000437
General Brands
Wieland
General Color
Gray
General Degree Of Protection Ip
Other
General Housing Material
Aluminum
General Inflammability Class Of Insulation Material According Wi
Other
General Maximum Operating Temperature Range
120 ºC
General Minimum Operating Temperature Range
-40 ºC
General Model
HOOD BAS GOT GG 40HM40 50 A1
General Surface
With Powder Coating
General Ultraviolet Uv Resistant
Yes
Model Cable Entry
Sideways
Model Construction
16H
Model Emc Version
No
Model Height
76 mm
Model Hinged Lid
No
Model Length
94 mm
Model Locking Mechanism
Single Locking Lever
Model Thread Size M
40
Model Type
Male
Model Type Of Cable
Thread
Model Width
43 mm
Model With Cable Screw Gland
No
Product Compliance Reach Svhc Cas Numbers
7439-92-1
Product Compliance Reach Svhc Conformity Status
Duty-To-Declare
Product Compliance Reach Svhc Substances
Lead
Product Compliance Rohs Conformity Status
Compliant with Exceptions
Product Compliance Rohs Exceptions
III-6(a)
Specifications Number Of Poles
40
Specifications Profile
Low
