Wieland 5-Pole Light Blue Female Connector - 20A Pluggable Electrical Connector
Wieland 5-Pole Light Blue Female Connector - 20A Pluggable Electrical Connector
SKU:CIR-0df3df
Secure outdoor electrical connections with the Wieland 5-Pole Light Blue Female Connector. 20A rated current, IP69 protection. Meets IEC and cULus standards.
Regular price
$24.99
Regular price
Sale price
$24.99
Unit price
per
Initiate Order
Wieland 5-Pole Light Blue Female Connector - 20A Pluggable Electrical Connector
$24.99
Quantity: 1
Claim Your Seller Account
Wieland 5-Pole Light Blue Female Connector - 20A Pluggable Electrical Connector
$24.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Experience secure outdoor electrical connections with the Wieland 5-Pole Light Blue Female Connector. Featuring a straight angle plug with screw connection, this connector offers a rated current of 20A and a durable design with IP69 and Type 4X / 6P protection. Suitable for cables with diameters ranging from 10mm to 14mm, this connector meets IEC and cULus wire size standards, ensuring reliable performance. Ideal for institutional and government use due to compliance with various procurement standards.
Product Specifications
Note Note
Technical details are subject to change
Specifications Angle Of Plug
Straight
Specifications Color Of Codingcontact Carrier
Light Blue
Specifications Connection Type
Screw Connection
Specifications Number Of Poles
5
Specifications Type
Female
Technical Data Alternating Current Ac Voltage Disconnect Under L
350 V
Technical Data Current Disconnect Under Load Usa And Canada
20 A
Technical Data Degree Of Protection According To Canadian Ul Lis
Type 4X / 6P
Technical Data Degree Of Protection According To International E
IP69
Technical Data Maximum Cable Diameter
14 mm
Technical Data Maximum Rated Voltage
600 V
Technical Data Minimum Cable Diameter
10 mm
Technical Data Minimum Rated Voltage
250 V | 400 V
Technical Data Rated Current
20 A
Technical Data Wire Size According To Canadian Ul Listed United
18 to 14 AWG
Technical Data Wire Size According To International Electrotechn
0.75 to 4 mm²
