Wieland 5-Pole Light Gray Female Connector 20A
Wieland 5-Pole Light Gray Female Connector 20A
SKU:CIR-62e358
Durable 5-Pole Light Gray Female Connector, 20A, Outdoor Rated for secure screw connections in challenging environments.
Regular price
$24.99
Regular price
Sale price
$24.99
Unit price
per
Initiate Order
Wieland 5-Pole Light Gray Female Connector 20A
$24.99
Quantity: 1
Claim Your Seller Account
Wieland 5-Pole Light Gray Female Connector 20A
$24.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland 5-Pole Light Gray Female Connector is a durable pluggable electrical connector suitable for outdoor use. With a straight angle of plug and IP69 rated protection, this connector ensures secure and reliable screw connections for cables ranging from 6mm to 10mm in diameter. It complies with international standards for rated voltage up to 600V and rated current of 20A. Designed for rugged outdoor environments, this connector is ideal for applications requiring high performance and robust connectivity.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Note Note
Technical details are subject to change
Specifications Angle Of Plug
Straight
Specifications Color Of Codingcontact Carrier
Light Gray
Specifications Connection Type
Screw Connection
Specifications Number Of Poles
5
Specifications Type
Female
Technical Data Alternating Current Ac Voltage Disconnect Under L
350 V
Technical Data Current Disconnect Under Load Usa And Canada
20 A
Technical Data Degree Of Protection According To Canadian Ul Lis
Type 4X / 6P
Technical Data Degree Of Protection According To International E
IP69
Technical Data Maximum Cable Diameter
10 mm
Technical Data Maximum Rated Voltage
600 V
Technical Data Minimum Cable Diameter
6 mm
Technical Data Minimum Rated Voltage
250 V | 400 V
Technical Data Rated Current
20 A
Technical Data Wire Size According To Canadian Ul Listed United
18 to 14 AWG
Technical Data Wire Size According To International Electrotechn
0.75 to 4 mm²
