Wieland 5-Pole Light Gray Male Connector

Name: Wieland 5-Pole Light Gray Male Connector
Brand: Wieland Electric Inc.
SKU: CIR-65ee83
Price: 29.99 USD
Availability: OutOfStock

SKU:CIR-65ee83

High-quality Wieland 5-Pole Light Gray Male Connector for secure outdoor electrical connections.

$29.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The Wieland 5-Pole Light Gray Male Connector is a high-quality pluggable electrical connector designed for outdoor applications. With an angled 90-degree plug and screw connection type, this connector ensures secure and reliable connectivity. It features a 20 A rated current, IP69 and Type 4X/6P protection ratings, and is suitable for cable diameters ranging from 10mm to 14mm. Compliant with IEC and cULus wire size standards, this connector is a durable and efficient solution for your electrical connection needs.

Product Specifications

Note Note

Technical details are subject to change

Specifications Angle Of Plug

Angled 90Âº

Specifications Color Of Codingcontact Carrier

Light Gray

Specifications Connection Type

Screw Connection

Specifications Number Of Poles

Specifications Type

Male

Technical Data Alternating Current Ac Voltage Disconnect Under L

350 V

Technical Data Current Disconnect Under Load Usa And Canada

20 A

Technical Data Degree Of Protection According To Canadian Ul Lis

Type 4X / 6P

Technical Data Degree Of Protection According To International E

IP69

Technical Data Maximum Cable Diameter

14 mm

Technical Data Maximum Rated Voltage

600 V

Technical Data Minimum Cable Diameter

10 mm

Technical Data Minimum Rated Voltage

250 V | 400 V

Technical Data Rated Current

20 A

Technical Data Wire Size According To Canadian Ul Listed United

18 to 14 AWG

Technical Data Wire Size According To International Electrotechn

0.75 to 4 mmÂ²
