Wieland 5-Pole Light Gray Male Connector
Wieland 5-Pole Light Gray Male Connector
SKU:CIR-be1fcd
Durable 5-Pole Light Gray Male Connector with 20A Rating for secure outdoor electrical connections.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
Wieland 5-Pole Light Gray Male Connector
$29.99
Quantity: 1
Claim Your Seller Account
Wieland 5-Pole Light Gray Male Connector
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland 5-Pole Light Gray Male Connector is a highly durable pluggable electrical connector suitable for outdoor use. Featuring a 20A rated current, IP69 protection, and a color-coded light gray contact carrier, this connector ensures secure and reliable electrical connections. With a screw connection type and compatibility with cable diameters ranging from 6mm to 10mm, it meets rigorous industry standards for performance and safety.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Note Note
Technical details are subject to change
Specifications Angle Of Plug
Angled 90º
Specifications Color Of Codingcontact Carrier
Light Gray
Specifications Connection Type
Screw Connection
Specifications Number Of Poles
5
Specifications Type
Male
Technical Data Alternating Current Ac Voltage Disconnect Under L
350 V
Technical Data Current Disconnect Under Load Usa And Canada
20 A
Technical Data Degree Of Protection According To Canadian Ul Lis
Type 4X / 6P
Technical Data Degree Of Protection According To International E
IP69
Technical Data Maximum Cable Diameter
10 mm
Technical Data Maximum Rated Voltage
600 V
Technical Data Minimum Cable Diameter
6 mm
Technical Data Minimum Rated Voltage
250 V | 400 V
Technical Data Rated Current
20 A
Technical Data Wire Size According To Canadian Ul Listed United
18 to 14 AWG
Technical Data Wire Size According To International Electrotechn
0.75 to 4 mm²
