Wieland 5-Pole Light Gray Male Pluggable Connector - 16A
Wieland 5-Pole Light Gray Male Pluggable Connector - 16A
SKU:CIR-7b9aa5
Reliable 5-Pole Light Gray Male Pluggable Connector - 16A, Ideal for Outdoor Use
Regular price
$24.99
Regular price
Sale price
$24.99
Unit price
per
Initiate Order
Wieland 5-Pole Light Gray Male Pluggable Connector - 16A
$24.99
Quantity: 1
Claim Your Seller Account
Wieland 5-Pole Light Gray Male Pluggable Connector - 16A
$24.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland 5-Pole Light Gray Male Pluggable Electrical Connector is a robust and reliable solution for outdoor applications. With a straight angle of plug and screw connection, this connector can accommodate cables ranging from 7.1mm to 13mm in diameter. It meets stringent industry standards with a rated current of 16A, IP69 protection level, and compatibility with wire sizes from 0.25 to 2.5mm² (IEC) or 22 to 16 AWG (cULus). Ensure secure and efficient electrical connections with this high-quality connector.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
General Angle Of Plug
Straight
General Brands
Wieland
General Color Of Codingcontact Carrier
Light Gray
General Connection Type
Screw Connection
General Number Of Poles
5
General Type
Male
Note Note
Technical details are subject to change
Technical Data Alternating Current Ac Voltage Disconnect Under L
350 V
Technical Data Current Disconnect Under Load
16 A
Technical Data Degree Of Protection According To Canadian Ul Lis
Type 4X / 6P
Technical Data Degree Of Protection According To International E
IP69
Technical Data Maximum Cable Diameter
13 mm
Technical Data Maximum Rated Voltage
600 V
Technical Data Minimum Cable Diameter
7.1 mm
Technical Data Minimum Rated Voltage
250 V | 400 V
Technical Data Rated Current
16 A
Technical Data Wire Size According To Canadian Ul Listed United
22 to 16 AWG
Technical Data Wire Size According To International Electrotechn
0.25 to 2.5 mm²
