Wieland 5-Pole Turquoise Blue Female Connector - 20A

Name: Wieland 5-Pole Turquoise Blue Female Connector - 20A
Brand: Wieland Electric Inc.
SKU: CIR-5569c5
Price: 24.99 USD
Availability: OutOfStock

SKU:CIR-5569c5

Durable 5-Pole Turquoise Blue Female Connector - 20A, IP69 & Type 4X/6P protection, IEC/cULus compliant

$24.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The Wieland 5-Pole Turquoise Blue Female Connector is a durable pluggable electrical connector designed for outdoor applications. With an angled 90-degree plug for convenience, this connector features a screw connection and meets IP69 and Type 4X / 6P protection standards. Suitable for cables ranging from 6mm to 10mm in diameter, it has a rated current of 20A and can handle voltages up to 600V. Compliant with IEC and cULus wire size standards, this connector ensures reliable connectivity in demanding environments.

Product Specifications

Note Note

Technical details are subject to change

Specifications Angle Of Plug

Angled 90Âº

Specifications Color Of Codingcontact Carrier

Turquoise Blue

Specifications Connection Type

Screw Connection

Specifications Number Of Poles

Specifications Type

Female

Technical Data Alternating Current Ac Voltage Disconnect Under L

350 V

Technical Data Current Disconnect Under Load Usa And Canada

20 A

Technical Data Degree Of Protection According To Canadian Ul Lis

Type 4X / 6P

Technical Data Degree Of Protection According To International E

IP69

Technical Data Maximum Cable Diameter

10 mm

Technical Data Maximum Rated Voltage

600 V

Technical Data Minimum Cable Diameter

6 mm

Technical Data Minimum Rated Voltage

250 V | 400 V

Technical Data Rated Current

20 A

Technical Data Wire Size According To Canadian Ul Listed United

18 to 14 AWG

Technical Data Wire Size According To International Electrotechn

0.75 to 4 mmÂ²

Wieland 5-Pole Turquoise Blue Female Connector - 20A
