Wieland 5-Pole Turquoise Blue Male Connector
Wieland 5-Pole Turquoise Blue Male Connector
SKU:CIR-6a6af5
High-quality 5-Pole Turquoise Blue Male Connector for outdoor use, featuring screw connection and IP69 protection.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
Wieland 5-Pole Turquoise Blue Male Connector
$29.99
Quantity: 1
Claim Your Seller Account
Wieland 5-Pole Turquoise Blue Male Connector
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland 5-Pole Turquoise Blue Male Connector is a high-quality pluggable electrical connector designed for outdoor applications. With a straight angle plug and screw connection, this connector ensures secure and reliable electrical connections. It features a color-coded contact carrier in turquoise blue, making identification easy. Rated for 20 A current and compatible with cables ranging from 10mm to 14mm in diameter, this connector meets IP69 and Type 4X / 6P protection standards, suitable for demanding outdoor environments.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Note Note
Technical details are subject to change
Specifications Angle Of Plug
Straight
Specifications Color Of Codingcontact Carrier
Turquoise Blue
Specifications Connection Type
Screw Connection
Specifications Number Of Poles
5
Specifications Type
Male
Technical Data Alternating Current Ac Voltage Disconnect Under L
350 V
Technical Data Current Disconnect Under Load Usa And Canada
20 A
Technical Data Degree Of Protection According To Canadian Ul Lis
Type 4X / 6P
Technical Data Degree Of Protection According To International E
IP69
Technical Data Maximum Cable Diameter
14 mm
Technical Data Maximum Rated Voltage
600 V
Technical Data Minimum Cable Diameter
10 mm
Technical Data Minimum Rated Voltage
250 V | 400 V
Technical Data Rated Current
20 A
Technical Data Wire Size According To Canadian Ul Listed United
18 to 14 AWG
Technical Data Wire Size According To International Electrotechn
0.75 to 4 mm²
