Wieland 5-Pole Turquoise Blue Male Electrical Connector
Wieland 5-Pole Turquoise Blue Male Electrical Connector
SKU:CIR-77c9d8
Reliable Wieland 5-Pole Turquoise Blue Electrical Connector for outdoor applications. Supports 20A current rating with IP69 protection.
Regular price
$24.99
Regular price
Sale price
$24.99
Unit price
per
Initiate Order
Wieland 5-Pole Turquoise Blue Male Electrical Connector
$24.99
Quantity: 1
Claim Your Seller Account
Wieland 5-Pole Turquoise Blue Male Electrical Connector
$24.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland 5-Pole Turquoise Blue Male Connector is a high-quality pluggable electrical connector designed for outdoor use. With a straight angle plug and screw connection, this connector is suitable for a variety of applications requiring a secure and reliable electrical connection. It supports a rated current of 20 A and can accommodate cable diameters ranging from 10mm to 14mm. Meeting IP69 and Type 4X/6P protection standards, this connector ensures durability and safety in challenging environments.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Note Note
Technical details are subject to change
Specifications Angle Of Plug
Straight
Specifications Color Of Codingcontact Carrier
Turquoise Blue
Specifications Connection Type
Screw Connection
Specifications Number Of Poles
5
Specifications Type
Male
Technical Data Alternating Current Ac Voltage Disconnect Under L
350 V
Technical Data Current Disconnect Under Load Usa And Canada
20 A
Technical Data Degree Of Protection According To Canadian Ul Lis
Type 4X / 6P
Technical Data Degree Of Protection According To International E
IP69
Technical Data Maximum Cable Diameter
14 mm
Technical Data Maximum Rated Voltage
600 V
Technical Data Minimum Cable Diameter
10 mm
Technical Data Minimum Rated Voltage
250 V | 400 V
Technical Data Rated Current
20 A
Technical Data Wire Size According To Canadian Ul Listed United
18 to 14 AWG
Technical Data Wire Size According To International Electrotechn
0.75 to 4 mm²
