Wieland 5-Pole Yellow Female Connector - 20A
Wieland 5-Pole Yellow Female Connector - 20A
SKU:CIR-e197fe
Durable Wieland 5-Pole Yellow Female Connector - 20A, IP69-rated for outdoor use. Supports cable diameters 10-14mm, ideal for various applications.
Regular price
$24.99
Regular price
Sale price
$24.99
Unit price
per
Initiate Order
Wieland 5-Pole Yellow Female Connector - 20A
$24.99
Quantity: 1
Claim Your Seller Account
Wieland 5-Pole Yellow Female Connector - 20A
$24.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland 5-Pole Yellow Female Connector is a high-quality pluggable electrical connector suitable for outdoor use. With a straight angle of plug, screw connection type, and IP69 protection rating, this connector is designed for durability and performance in demanding environments. It supports a minimum cable diameter of 10mm up to 14mm and has a rated current of 20A, making it ideal for various electrical applications. Compliant with international standards, including IEC and cULus, this connector ensures reliable and safe connectivity.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Note Note
Technical details are subject to change
Specifications Angle Of Plug
Straight
Specifications Color Of Codingcontact Carrier
Yellow
Specifications Connection Type
Screw Connection
Specifications Number Of Poles
5
Specifications Type
Female
Technical Data Alternating Current Ac Voltage Disconnect Under L
350 V
Technical Data Current Disconnect Under Load Usa And Canada
20 A
Technical Data Degree Of Protection According To Canadian Ul Lis
Type 4X / 6P
Technical Data Degree Of Protection According To International E
IP69
Technical Data Maximum Cable Diameter
14 mm
Technical Data Maximum Rated Voltage
600 V
Technical Data Minimum Cable Diameter
10 mm
Technical Data Minimum Rated Voltage
250 V | 400 V
Technical Data Rated Current
20 A
Technical Data Wire Size According To Canadian Ul Listed United
18 to 14 AWG
Technical Data Wire Size According To International Electrotechn
0.75 to 4 mm²
