Wieland 5-Pole Yellow Male Connector
Wieland 5-Pole Yellow Male Connector
SKU:CIR-90b149
Reliable 5-Pole Yellow Male Connector for outdoor use, 20A rated current, IP69 protection, IEC/cULus compliant.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
Wieland 5-Pole Yellow Male Connector
$29.99
Quantity: 1
Claim Your Seller Account
Wieland 5-Pole Yellow Male Connector
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland 5-Pole Yellow Male Connector offers a reliable pluggable electrical connection for outdoor use. With a 20A rated current and IP69 protection rating, this connector is designed for durability and safety. It features a screw connection and can accommodate cables ranging from 10mm to 14mm in diameter. Compliant with IEC and cULus wire size standards, this connector is suitable for a wide range of applications.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Note Note
Technical details are subject to change
Specifications Angle Of Plug
Straight
Specifications Color Of Codingcontact Carrier
Yellow
Specifications Connection Type
Screw Connection
Specifications Number Of Poles
5
Specifications Type
Male
Technical Data Alternating Current Ac Voltage Disconnect Under L
350 V
Technical Data Current Disconnect Under Load Usa And Canada
20 A
Technical Data Degree Of Protection According To Canadian Ul Lis
Type 4X / 6P
Technical Data Degree Of Protection According To International E
IP69
Technical Data Maximum Cable Diameter
14 mm
Technical Data Maximum Rated Voltage
600 V
Technical Data Minimum Cable Diameter
10 mm
Technical Data Minimum Rated Voltage
250 V | 400 V
Technical Data Rated Current
20 A
Technical Data Wire Size According To Canadian Ul Listed United
18 to 14 AWG
Technical Data Wire Size According To International Electrotechn
0.75 to 4 mm²
